ARTS M ARATHONER G OLD & S ILVER S TAR G AS C ONVECTION O VENS
P AGE 70 O PERATOR ’ S M ANUAL 1181887 REV 1
PA
RT
S
Storage Rack Parts
1
2
3 4 5
6
7
Key Part Number Qty Description
1-7 1175506 1 Cooling rack kit, with shelf, shallow depth
1175507 1 Cooling rack kit, with shelf, bakery depth
1175508 1 Cooling rack kit, w/o shelf, shallow depth
1175509 1 Cooling rack kit, w/o shelf, bakery depth
1 1175296 2 Rack hanger, G/E ser co
2 1175514 1 Stop channel
3 1175438 2 Rack guide, 11 pos. shallow
1175439 2 Rack guide, 11 pos. bakery
4 6660 8 Clip, side rack support
5 1175294 1 Shelf, open rack, shallow
1175295 1 Shelf, open rack, bakery
6 1175504 1 Front channel frame
7 1175505 1 Rear channel frame
* 1146304 18 10 x 1/2 Phillips screw
* not shown on drawing.
