Control Panel Parts for Cycle/Cook and Hold Models (CCH Models)
See drawing on following page.
Key
Part Number
Qty
Description
1-20
1180409
1
Control panel assembly, CCH, 60Hz, M-Gold, 120V (assembled, w/o wiring harness)
1-21
1180485
1
Control panel assembly, CCH, 60Hz, M-Gold, 208/240V (assembled, w/o wiring harness)
1-20
1180410
1
Control panel assembly, CCH, 60Hz, SilverStar, 120V, w/lights (assembled, w/o wiring harness)
1-20
1180492
1
Control panel assembly, CCH, 60Hz, SilverStar, 120V, w/o lights (assembled, w/o wiring harness)
1-21
1180486
1
Control panel assembly, CCH, 60Hz, SilverStar, 208/240V, w/lights (assembled, w/o wiring harness)
1-21
1180494
1
Control panel assembly, CCH, 60Hz, SilverStar, 208/240V, w/o lights (assembled, w/o wiring harness)
*
1180482
1
Wiring harness, CCH, 120V (includes terminal block 1170335)
1180483
1
Wiring harness, CCH, 208/240V (includes terminal block 1170335)
1
1180479
1
Front control panel s/a, CCH
2
1180350
1
Polypanel, CCH, M-Gold
1180411
1
Polypanel, CCH, SilverStar
3
1177541
1
Rocker switch-DPST- (on-off)
4
1177598
1
Valve location label
5
1177540
2
Rocker switch-SPDT (on-on)
6
1180402
1
Relay, 120V
1180499
1
Relay, 208/240V
7
6600430
8
Locknut, #8-32
8
1146397
6
Screw, #8-32x5/8 pan head
9
1180404
4
Spacer, control
10
1146400
4
Nut, #6-32 hex
11
1180407
1
Control, CCH
12
1177515
1
Clamp, RAM module
13
1146362
2
Screw, #8-32x1-5/8 Phillips truss head
14
1175723
1
Ignition control module 24VAC
15
1172277
1
Transformer, 120/208/240-24V
16
1170335
1
Terminal block
17
1170336
1
Marker strip
18
1175046
1
Left control panel hinge
19
1177789
1
Rocker switch-SPST momentary (for models with the oven light option)
1177642
1
Plug, square (for models without the oven light option)
20
1177564
2
Plug, round (120V models)
1170424
2
Fuse holder (208/240V models)
21
1170425
2
Fuse, 12 amp #LP-CC-12 low peak (208/240V models only)
*
1181996
1
Temperature probe
* not shown on drawing.
