P
ARTS M ARATHONER G OLD & S ILVER S TAR G AS C ONVECTION O VENS
P AGE 54 O PERATOR ’ S M ANUAL 1181887 REV 1
PA
RT
S
Door Parts
1
2
4
5
6
8
9
2
7
3
Key Part Number Qty Description
1 1177102 1 Handle, coated, 15"
2 1164527 4 Bushing, bronze, lower oil lite
3 1092000 6 Oilite thrust bearing
4 1178049 1 Center door seal (for units built before February 15, 2001)
1181803 1 Center door seal (for units built after February 14, 2001)
5 1181923 1 Door assembly, left, 60%, window, co
1181921 1 Door assembly, left, 60%, solid, co
6 1181924 1 Door assembly, right, 40%, window, co
1181922 1 Door assembly, right, 40%, solid, co
7 1181865 2 Door seal, left & right, co
8 1181826 1 Door seal, bottom, co
9 1181829 1 Door seal, top, co
