SV Sound
Chapter 9-1
Specifications
Model Name:
PC12-Plus
Configuration:
Powered Cylinder, 12” woofer
Design:
Vented, Variable Tune
Dimensions:
40” High x 16” Wide
H x W x D
102 cm H. x 41 cm W.
Weight:
55lbs (25kg)
Voltage (fixed):
110~120V/60hz (US/Canada/South America)
220~240V/50hz (Europe, Russia, other)
Driver:
12” SVS designed/built “Plus” woofer with high
-excursion synthetic surround, aluminum cone
with cast basket, high-temp US voice coil and
integral cooling vents
Frequency Response:
(quasi-anechoic)
20Hz - 150Hz ± 3dB (typical in-room response
3-5Hz deeper) with 20hz tuning
Inputs/Outputs:
RCA (low level) plus speaker level
Controls:
Gain, continuously variable phase, crossover
(defeatable), auto on, PEQ, variable tuning
and high-pass filter switches
Power Handling:
525 watt RMS
Crossover:
High pass: 12dB/octave @ 80Hz
Variable low pass: 12dB/octave (40-120Hz)
Enclosure Material:
1.5” birch end-caps, .25” wood fiber cylinder
tubing with polymer wrap, black fabric cover
