Your 3 in 1 Family Thermometer:
operation and advantages Page 2-3
Important safety instructions Page 3
Features and Components Page 4
Control displays and symbols Page 5-6
Changing from Celsius to Fahrenheit
and vice-versa Page 6
Measuring the temperature Page 6-8
How to recall 10 readings in
memory mode Page 9
Cleaning and storage Page 9
Battery replacement Page 10
Technical specifi cations Page 11
Warranty Page 12
EN12470-3: 2000, clinical thermometers
ASTM E1112- 00 standard Reference to standards EN12470-3: 2000, clinical thermometers
ASTM E1112- 00 standard EN12470-3: 2000, clinical thermometers
ASTM E1112- 00 standard Reference to standards
Complete a Measurement in 5/6/7 Seconds
The innovative predictive technology incorporated in the thermometer
allows calculation in 5/6/7 seconds (rectal/oral/underarm).
Ergonomic Probe Shape
Ergonomic probe shape for each measuring site (oral, underarm, and
rectal). This makes the measurement more comfortable and reliable
Accurate and Reliable
Accuracy of measurements with the thermometer is comparable to
that of a conventional pen-type one.
Fever Indicator
RED backlight will be on for 5 seconds if reading is equal to or higher
than 99.5°F (37.5°C).
Lighted Large Display
Large display with backlight makes the thermometer easy to use
and read.
TABLE OF CONTENTS
YOUR 3 IN 1 FAMILY THERMOMETER:
OPERATION AND ADVANTAGES
2 11
TECHNICAL SPECIFICATIONS (CONT.)
Description Features
Turn on the unit. It will automatically
display the last reading for 2 seconds
after display check. Memory function Turn on the unit. It will automatically
display the last reading for 2 seconds
after display check. Turn on the unit. It will automatically
display the last reading for 2 seconds
after display check. Memory function
Around 3 and a half min. ±30 seconds
after the measurement is completed. Auto Power-Off function Around 3 and a half min. ±30 seconds
after the measurement is completed. Around 3 and a half min. ±30 seconds
after the measurement is completed. Auto Power-Off function
Displays “Lo” when the measurement is
lower than 89.6°F (32°C) and “Hi” when
higher than 109.2°F (42.9°C) Out-of-range indication Displays “Lo” when the measurement is
lower than 89.6°F (32°C) and “Hi” when
higher than 109.2°F (42.9°C) Displays “Lo” when the measurement is
lower than 89.6°F (32°C) and “Hi” when
higher than 109.2°F (42.9°C) Out-of-range indication
When the battery voltage drops to the
low level, the symbol
“ “ will appear
on LCD.
Low battery indication When the battery voltage drops to the
low level, the symbol
on LCD. When the battery voltage drops to the
low level, the symbol
on LCD. Low battery indication
It runs automatically after power on.
Display “Err” when system malfunction.
50~104°F (10~40°C), 15~95%R.H.
noncondension Operating temperature 50~104°F (10~40°C), 15~95%R.H.
noncondension 50~104°F (10~40°C), 15~95%R.H.
noncondension Operating temperature
Self-test function It runs automatically after power on.
Display “Err” when system malfunction. It runs automatically after power on.
Display “Err” when system malfunction. Self-test function
-4°F to 140°F (-20°C to +60°C) Storage temperature -4°F to 140°F (-20°C to +60°C) -4°F to 140°F (-20°C to +60°C) Storage temperature
Please observe the applicable disposal regulations to dispose of the
instrument and the batteries.
a. 1 beep sound is made when power
ON or OFF.
b. 5 beeps are made after the
measuring is completed.
Beeper function a. 1 beep sound is made when power
ON or OFF.
b. 5 beeps are made after the
measuring is completed.
a. 1 beep sound is made when power
ON or OFF.
b. 5 beeps are made after the
measuring is completed.
Beeper function
