E LECTRICAL S PECIFICATION SSD-P XXX (I)-3100 D ATA S HEET
S ILICON S YSTEMS P ROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3100P-06DSR P AGE 15 F EBRUARY 2, 2009
A BSOLUTE M AXIMUM R ATINGS
-WE
(True IDE mode) In true IDE mode, this input signal is
not used and should be connected to
V
CC
by the host.
WP
(PC Card memory
mode) 24 O
Write Protect Memory Mode.
The
SiliconDrive CF does not have a write
protect switch. This signal is held low
after the completion of the reset
initialization sequence.
-IOIS16
(PC Card I/O
mode) I/O Operation. When the SiliconDrive
CF is configured for I/O operation, pin
24 is used for the -I/O Selected, which
is a 16-bit port (-IOIS16) function. A
low signal indicates that a 16-bit or
odd byte only operation can be
performed at the addressed port.
-IOIS16
(True IDE mode) In true IDE mode, this output signal is
asserted low when this device is
expecting a word data transfer cycle.
Table 8: Signal Descriptions (Continued)
Signal Name Pin Type Description
Table 9: Absolute Maximum Ratings
Symbol Parameter Minimum Maximum Units
T
s
Storage Temperature -55 125 °C
T
A
Operating Temperature -40 85 °C
V
CC
V
CC
with Respect to GND -0.3 6.7 V
V
in
Input Voltage -0.5 3.8 V
V
out
Output Voltage -0.3 3.6 V
