36 SBC-770 User Manual
USB connector (CN14)
The SBC-770 provides two USB (Universal Serial Bus) interfaces,
which give complete plug and play, hot attach/detach for up to 127
external devices. The USB interfaces comply with USB specifica-
tion Rev. 1.0, and can be disabled in the system BIOS setup.
USB connector (CN14)
Pin Function Pin Function
1 Vcc 6 Vcc
2 USBDO- 7 USBD1-
3 USBDO+ 8 USBD1+
4 GND 9 GND
5 GND 10 N.C.
