Wiring Diagram
Shock Sensor
Green - Lock Out (-) 500mA
Blue - Unlock Out (-) 500mA
Valet Switch
LED
Orange - Ground when Armed Output (-) 500mA
Blue - Hood/Trunk Trigger Input (-)
Black/White -Domelight/ Aux. 2 Output (-)500mA
Brown/White - Horn Output (-)500mA
Gray - Auxiliary 1 Output (-)500mA
Brown - Siren Output (+)3A
Green - Door Trigger Input (-)
Purple - Door Trigger Input (+)
White - Parking Light Output (+)10A
Red - +12V Battery Input (+)
Yellow -+12v Ignition Input
Black - Negative Ground Input (-)
Red
Blue
Control Unit
G25/G20
