MOON P 5.3 Stereo Preamplifier
Specifications
Configuration ......................................................... Stereo
Power Supply Transformers ..................................... 1 x 10VA (for audio); 1 x 10VA (controller circuitry)
Power Supply Capacitance ...................................... 26,400µF
Circuit Topology ...................................................... Open Loop
Balanced inputs (XLR) ........................................... 1 pairs
Single-ended inputs (RCA) ..................................... 4 pairs
Input Impedance ................................................... 22,000
Ω
Input Sensitivity ..................................................... 200mV – 4.0V RMS
Balanced outputs (XLR) .......................................... 1 pair
Single-ended outputs (RCA) .................................... 2 pairs (fixed and variable)
Output Impedance (RCA / XLR) ................................ 50
Ω / 100Ω
Gain Control ........................................................... M-eVOL
Gain ....................................................................... 9dB
Signal-to-noise Ratio (20Hz-20kHz) ......................... 109dB @ full output
Maximum Output Voltage (Balanced) ........................ 12 Volts
Maximum Output Voltage (Single-Ended) .................. 6 Volts
Frequency Response .............................................. 5Hz - 100kHz +0/-0.1dB
Crosstalk @ 1kHz ................................................... < -110dB
Intermodulation Distortion ...................................... Unmeasureable
THD (20Hz - 20kHz) .............................................. < 0.002%
Remote Control ...................................................... All Aluminum Full-Function (FRM-2)
Power Consumption @ idle ..................................... 6 Watts
AC Power Requirements ......................................... 120V / 60Hz or 240V / 50Hz
Shipping Weight ..................................................... 25 lbs / 11 Kgs
Dimensions (W x H x D, inches) .............................. 17 x 4 x 15
Balanced Input and Output Pin Assignment:
Pin 1................................ Ground
Pin 2................................ Positive
Pin 3 .............................. Negative
Optional Phono Section:
Input Impedance - Adjustable ................................. 100 Ω and 47kΩ
Input Capacitance - Adjustable ............................... 0pF and 100pF
Gain – Adjustable .................................................. 40dB and 60dB
Input overload @ 40dB/60dB gain ............................ 58mV RMS / 3mV RMS
Signal-to-noise Ratio (full scale @ 40dB/60dB gain) 107dBr / 85dBr
Frequency Response ............................................... 20Hz - 20kHz (
± 0.5dB)
Intermodulation Distortion ...................................... < 0.009%
THD (20Hz - 20kHz) .............................................. < 0.001%
Crosstalk @ 1kHz ................................................... -97dB
Fuse Replacement: For the 120V version use a 0.2A slow blow (5 x 20mm size).
For the 230V version use a 0.1A slow blow (5 x 20mm size).
____________________________________________________________________________________
Specifications 14
