Smooth Fitness 5.15P User Manual
Page 12
SMOOTH 5.15P MOTORIZED TREADMILL
Visit us at: www.smoothfitness.com
12
ASSEMBLY
STEP 3:
Rotate the Console Support (28) and secure with the Console Support Locating Screw (101). Rotate the Console (26) and
secure with Screws (88). Screws (88) are already pre-assembled (please refer to the exploded diagram). Attach the Right
Handlebar Front End Caps (95 and 97) to the Right Handlebar (23) and secure using Screws (87 and 81). Repeat the same
procedure for the Left Front End Caps (94 and 96).
