SVAT Electronics VU5 User Manual
Page 4
SVAT ELECTRONICS
now you can see
VU5
1
Table of Contents
1.WHAT IS INCLUDED .........................................................................................................................................................................1
2. CAMERA FEATURES AND FUNCTIONS .........................................................................................................................................................................................................1
3.INSTALLATION ................................................................................................................................................................................2
4. MOUNTING ....................................................................................................................................................................................2
5. STEP BY STEP .................................................................................................................................................................................2
6. TROUBLESHOOTING .......................................................................................................................................................................3
7. SPECIFICATIONS .............................................................................................................................................................................4
NOTES ..............................................................................................................................................................................................5
DRILLING TEMPLATE ..........................................................................................................................................................................6
WHAT IS INCLUDED
1 Indoor/Outdoor Night
Vision Color Camera
2 Window
Warning Stickers
60ft 4 PIN DIN to RCA
(male) Video/Power
Wire
•
BNC to RCA Connector
•
Power Adapter for Camera
• 1 Year Warranty
•
Instruction Manual
• Online/Toll Free Support
•
Mounting Hardware
CMOS Cameras
1. Sun Shield helps prevent glare from bright lights.
2. Infrared (IR) LEDs - Allow the camera to see in the dark up
to 15ft away.
3. CDS Sensor turns on the infrared LEDs when it gets dark out.
4. Camera Housing made of treated metal to prevent rust.
5. Camera Mount allows the camera to be desk or wall
mounted.
6 . Connection to Video / Power Wire - Converts to RCA from 4
PIN DIN.
CAMERA FEATURES AND FUNCTIONS
TABLE OF CONTENTS
1
2
3
4
5
6
