17
GC-STT-V BAG SUPPORT BRACKET AND SEAL
Ref. Part
No. Number Description
-NOTE-
Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased locally are a grade 5.
1 04090-02 Pop Rivet, 3/16 x .652
2 482321 Seal, Hood
3 04021-02 Lock Nut, 1/4-20 Center Lock
4 423312 Retainer, Seal
5 04003-02 Bolt, Carr. 1/4-20 x 3/4"
6 04001-08 Bolt, Hex Head 5/16-18 x 3/4"
7 04019-03 Nut, Serrated Flange 5/16-18
8 04021-10 Nut, Elastic Stop 5/16-18
9 04040-15 Flatwasher, 5/16-.375 x .875 x .083
10 423197 Tube, Bag Support
11 04003-12 Bolt, Carr. 5/16-18 x 3/4"
12 423198 Mount, Bag Frame Tube
13 482569 Bag Assembly, GC-STT
