Sharp MX-2600N - Manual (Page 8)

1
Some features require optional equipment.
2
Paper capacity is based on letter size paper.
3
Actual transmission time will vary based on line conditions.
4
Based on Sharp Standard Test Chart with approximately 700 characters,
letter size in standard resolution.
MX-2600N/MX-3100N
SPECIFICATIONS
Main Specifications
MX-2600N/3100N Includes multi-tasking controller, 80 GB HDD with document filing
system, PCL5c/PCL6 network printing, network scanning, 100-sheet RSPF,
auto-duplex, two 500-sheet paper drawers and 100-sheet bypass. Black
and color developer is included in the box.
Type Console, color multi-function digital document system
Functions Copy, print, network print, network scan, document filing and fax 1
Copy System Dry electrostatic transfer/Dual component developer/Magnetic brush
development/OPC drums/Heat Roller fusing/Xenon lamp exposure
Originals Sheets and bound documents
Max Original Size 11" x 17"
Copy Size Min. 5 ½" x 8 ½", Max. 11 "x 17" + 12" x 18"
Copy Speed MX-2600N: 26 ppm B&W/Color (8 ½” x 11”)
MX-3100N: 31 ppm B&W/Color (8 ½” x 11”)
Multiple Copy: Max. 999 copies
First Copy time: Platen glass: 6 seconds (B&W); 8.9 seconds (color) RSPF: 10.7 seconds
(B&W); 13.5 seconds (color) (Based on A4 original using tray 1 Auto color
selection & Auto color Polygon)
Warm Up Time 60 Seconds or less
Magnification 25% to 400% in 1% increments (with document feeder 25%-200%)
Original Feed 100-sheet RSPF with original size detection
Scan Speed Copy mode: Up to 50 OPM (B&W) @ 600 x 400 dpi; Up to 36 OPM (Color)
@ 600 x 600 dpi.
Network Scan: Up to 50 OPM (B&W or Color) 200 x 200 dpi.
All times based on single-side letter originals.
Original Sizes 5 ½" x 8 ½", 8 ½" x 11", 8 ½" x 11" R, 8 ½" x 14", 11" x 17" (13-32 lb. bond)
Paper Feed System Standard: (2) 500-sheet paper drawers (letter/legal/ledger/statement
size) and 100-sheet bypass tray (letter/legal/ledger/statement/
envelope size).
2
Optional: (1) 500-sheet paper drawer (letter/legal/ledger/statement size)
or (2) 500-sheet paper drawers (letter/legal/ledger/statement size)
and 3500-sheet large capacity tray (letter size). See your local dealer
for configurations.
Paper Types Paper drawers: 16 lb. bond -110 lb. index, large capacity tray:
16-28 lb. bond. Other paper types include plain, pre-printed, recycled,
pre-punched, letterhead and color paper. Bypass Tray: 16-28 lb. bond
(plain paper), 13-16 lb. bond (thin paper), 110-140 lb. index (heavy
paper), 20-24 lb. bond (Monarch/Com-10 envelope), tab paper (letter
size only). Other types include label paper, gloss paper, pre-printed,
recycled, pre-punched, letterhead, color paper and OHP film.
Duplexing Standard automatic duplex copying and printing
CPU Power QUICCIII-MPC8533E (800MHz)
Interface RJ-45 Ethernet (10/100/1000Base-T), USB 2.0 (host port),
USB 2.0 (device port)
Memory Standard 1 GB (copier); 512 MB (printer/network scanning) memory
Hard Disk Drive 80 GB; 38GB for document filing system and electronic sorting
Copy Resolution Scan: B&W/color: 600 DPI; Copy Output: B&W/color: 600 DPI
Color modes Auto Color Control (ACS), Full Color Mode, Monochrome (B/W), 2 Color
Mode, Single Color mode
Exposure Control Modes: Automatic (Color: Magical view, B/W: Character AE) Text, Text/
Photo, Text/Printed-Photo, Printed-Photo, Photo, Map, Pale-Color
document. Settings: Auto exposure control or 9 step manual exposure.
Halftone 256 gradiations/2 levels (monochrome)
Copy Features Scan-Once Print-Many, electronic sorting, offset-stacking, Auto Color
Sensing (ACS), Auto Paper Sensing (APS), Auto Magnification Sensing
(AMS), auto tray switching, rotation copy, reserve copy, tandem copy, book
copy, margin shift, tab-paper insertion, edge erase, center erase, dual page
copy, cover pages, insert pages, OHP insertion, job build, card shot,
multi-page enlargement, reverse image, black-white reversal, centering,
proof copy, 2-in-1/4-in1, pamphlet, photo repeat, document filing, account
management, job programs, date/character/page stamp (color).
Account Control Up to 1000 users. Supports user-number authentication (on device), login
name/password (on device) or login name/password (on device via LDAP
server) for Copy, Print, Scan, Fax and document management.
Output Tray Main output tray (top) 500 sheets (face down); optional eject tray
Capacity (right 1 side) 100 sheets (face down)
Firmware Flash ROM with local (USB), network update capability and firmware update
Management 1 to N with PAU (Printer Administration Utility)
Configuration Web-based management system with user/administrator level login
Method security, cloning (1 to N) with PAU and remote front panel access
Service/Maintanence Remote front panel access, remote access to service logs and click counts
Power AC 100-127 VAC, 60 HZ, 12 Amps
Power consumption Maximum: 1440 W or less
Weight Approx. 255 lbs. (base model)
Dimensions 23 1 ⁄ 4 " (w) x 27½" (d), x 37½" (h)
Network Printing System (standard)
PDL PCL ® 6/PCL5c compatible, optional Postscript 3, optional XPS
Resolution 1200 dpi, 600 dpi
Print Speed 26/31 pages per minute (8 ½" x 11")
Print Drivers Windows ® 98, Windows Me, Windows NT® 4 (with SP5 or later), Windows
2000, Windows Server® 2003, Windows XP, Windows XP x64, Windows
Server x64, Windows Vista™, Windows Vista x64, MAC OS
®, 9.2.2, OSX
(including 10.2.8, 10.3.9, 10.4.11, 10.5-10.5.1), all MAC PPD. Windows
Server 2008 drivers not available at time of launch.
Features Continuous printing, duplex printing, pamphlet printing, N-up printing,
image rotation, different cover page/last page, transparency inserts, tab
printing, carbon copy print mode, fit-to-page, poster print, margin shift,
mirror image, watermarks, overlay, confidential print, confidential batch
print, print hold, proof print, bypass printing, job priority printing, print job
control, tandem printing and direct printing (Note: some features not
available on certain print drivers).
Direct Printing File Types: TIFF, JPEG, PCL, PRN, TXT, PDF, Encrypted PDF, Postscript and XPS 1
Methods: FTP, Web page, E-mail and USB memory
Resident Fonts 80 outline fonts
Interface RJ-45 Ethernet 10/100/1000 Base-T
Operating Systems Windows 98/ME, NT 4.0, XP, 2003/2008 Server, Vista, Novell ® Netware®
3x, 4x, 5x, MAC OS 9, OSX (including 10.5.1), Sun ® OS 4.1x, Solaris® 2x,
Unix ®, Linux® and Citrix® (Metaframe, Presentation Server 4, 4.5) and
Windows Terminal Services.
Network Protocols TCP/IP (IPv4, IPv6, IPSEC) SSL (HTTP, IPP, FTP), SNMPv3, 802.1x for Windows
and Unix. LPD and LPR for UNIX. IPX/SPX
® for Novell environments.
EtherTalk ® and NetBEUI. AppleTalk® for Macintosh® environments.
Printing Protocols LPR, IPP, IPPS, PAP, Raw TCP (port 9100), FTP and Novell Pserver/Rprinter
Network Security IP/Mac address filtering, protocol filtering, port management, user
authentication and document administration.
Security Standards IEEE-2600, DoD (NSTISSP) #11, DoD Directive 8500.2, DoD (DISA)
Network Scanning System (standard)
Max Original Size 11" x 17"
Optical Resolution 600 DPI
Output Modes 600 dpi, 400 dpi, 300 dpi, 200 dpi, 100 dpi
Scan Modes Color, monochrome, grayscale
Image Formats Monochrome: TIFF, PDF, Encrypted PDF, XPS
Color: Grayscale, Color TIFF, JPG, PDF, Encrypted PDF, XPS
Internet Fax: TIFF-FX, FIFF-F, TIFF-S
1
Image Monochrome Scanning: Uncompressed, G3 (MH), G4 (MR/MMR)
Compression Color/Grayscale: JPEG (high, middle, low)
Internet Fax mode: MH/MMR (option)
Scan Destinations E-mail, Desktop, FTP, Folder (SMB), USB, Internet fax (option), Super G3
fax (option)
One-touch Destinations Up to 999 (combined scan destinations)
Group Destinations Up to 500
Programs 48 (combined)
Max. Jobs in Memory Up to 94
Network Protocols TCP/IP and SSL (includes HTTP, SMTP, LDAP, FTP, POP3), SMB, ESMTP and 802.1x.
Network Security E-mail server user authentication for LDAP and Active Directory
Software Sharpdesk desktop document management software (1 user license)
B&W Super G3 Fax Kit (option)
Transmission mode Super G3, G3
Modem Speed 33.6 KBPS 3
Compression Methods JBIG, MMR, MR, MH
Scanning Method Sheet fed simplex or duplex or book
Max.Transmit Resolution 400 DPI
Transmit Speed Approximately 2 Seconds with Super G3/JBIG 4
Auto Dialing Up to 999 (combined scan destinations)
Group Up to 500
Dial/ Destinations
Inbound Fax Forwards received fax data to E-mail
Routing
Long length Originals Up to 31.5" (for transmission)
Programs 48 (combined)
Memory 8 (exclusive)
Halftone 256 levels
Features Quick on-line transmission, direct transmission, F-Code transmission/
reception, rotate transmission, anti-junk fax reception, automatically staple
received faxes, secure fax release, out of paper memory reception, auto
redial, 2-in-1 reception, duplex reception transaction reports, activity
reports and PC fax.
Inner Finisher (option)
Type Built-in finisher (hole-punch unit option)
Output Capacity 500 sheets (letter/statement) or 250 sheets (ledger/legal size)
Output Delivery Face down
Stapling Media Plain paper, (letter, legal, or ledger size)
Stapling Positions 1 front, 1 rear, or both
Power Source Supplied from main unit
Stapling Up to 50 sheets (letter size) or 30 sheets (legal, ledger or mixed)
Stapled Sets 30 bundles or 500 sheets (letter or statement size) or 30 bundles or 250
sheets (legal or ledger size)
Hole Punching Optional hole punch unit MX-PNX1B (2 holes/3 holes)
Weight Approx: 28.7 lbs.
Dimensions 25.2" (w) x 28.94" (d) x 8.1" (h) (includes extended tray)
Saddle Stitch Finisher (option)
Type Console finisher with dual exit trays (mounts on left side of host machine)
Output Trays Upper tray: Offset stack tray
Lower tray: Book tray for saddle stitch
Output Capacity 1000 sheets (letter/statement size) or
500 sheets (legal, ledger or letter-R size)
Stapling Up to 50 sheets (letter/statement) or 25 sheets (legal, ledger or mixed)
Output Delivery Face down
Stapling Media Plain paper, letter/legal/ledger size or mixed
Stapling Positions 1 front, 1 rear, or both
Saddle Stitch Function Center stitch/center folding (2 staples) letter/legal/ledger paper sizes
Saddle Stitch Max. Sets Up to 10 sets (11-15 sheets per set)/15 sets (6-10 sheets per set)/20 sets
(1-5 sheets per set)
Power Consumption 70 W or less
Hole Punching Optional hole punch unit MX-PNX5B (2 holes/3 holes)
Weight Approx: 88.18 lbs.
Dimensions 25.83" (w) x 24.84" (d) x 38.9" (h) (with tray extended)
Large Capacity Tray (option)
Type Large capacity paper feed desk
Paper Size Letter size, 16-21 lbs. Bond
Capacity 3500 sheets
Paper Types Plain paper, pre-printed, recycled, letterhead, pre-punched
and colored paper
Power Source Supplied from main unit
Power Consumption 26.4 W, 40.8W when tray is rising
Weight Approx: 63.9 lbs.
Dimensions 14 9/16" (w) x 21 21/32" (d) x 20 15/32" (h)
Optional Equipment
MX-DEX6 Stand/1 x 500 Sheet Paper Drawer
MX-DEX7 Stand/2 x 500 Sheet Paper Drawer
MX-31ABD Rolling Cabinet Base
MX-LCX1 Large Capacity Tray (requires MX-DEX6 or MX-DEX7)
MX-FNX9 Inner Finisher
MX-FN10 Saddle Stitch Finisher
MX-RBX3 Paper Pass Unit (Required for MX-FN10)
MX-PNX1B 3 Hole Punch Unit (for Inner Finisher)
MX-PNX5B Punch Unit (for Saddle Stitch Finisher)
MX-TRX1 Exit Tray Unit
MX-PKX1 Postscript 3 kit
MX-PUX1 XPS Expansion Kit (Requires MX-SHP1GBXPS)
MX-SHP1GBXPS 1GB Memory Upgrade (Required for MX-PUX1)
MX-FWX1 Internet Fax kit
MX-FXX2 Fax Expansion Kit
AR-PF1 Bar Code Font kit
MX-AMX1 Application Integration Module
MX-AMX2 Application Communication Module
MX-AMX3 External Accounting Module
MX-FR10U Data Security kit (Commercial Version) Not available at time of launch
Supplies
MX-31NTBA Black Toner Cartridge
MX-31NTCA Cyan Toner Cartridge
MX-31NTMA Magenta Toner Cartridge
MX-31NTYA Yellow Toner Cartridge
MX-31NVBA Black Developer
MX-31NVSA Cyan/Magenta/Yellow Developer
MX-31NRSA Drum
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, NJ 07495-1163
1-800-BE-SHARP • www.sharpusa.com Design and Specifications subject to change without notice. Sharp, Sharp OSA, Sharpdesk,
My Sharp and all related trademarks are trademarks or registered trademarks of Sharp
Corporation and/or its affiliated companies. Windows, Windows NT, Windows Server and
Windows Vista are trademarks or registered trademarks of Microsoft Corporation. All
other trademarks are the property of their respective owners.
© 2008 Sharp Electronics Corporation. All rights reserved. Printed in U.S.A. 08/08 • CPD-3817
