7
Attaching the drum clamp to the drum
Drums / Percussions ( 908 D)
Attaching the microphone to the drum clamp
Drums / Percussions ( 908 D)
Position Commentary
To attach the MZH 908 D drum clamp, snap
it onto the rim of the drum as follows:
Put the upper part of the clip (1) onto the
rim and clip on by pushing down in a rota-
ting action (2) until it clips into place.
Position Commentary
To attach the microphone to the drum
clamp:
Loosen the knurled screw. Insert the
gooseneck of the microphone from the side
into one of the two slots and tighten the
knurled screw.
You can attach two microphones to the
drum clamp (e.g. for picking up two toms in
cramped space conditions). To do so, use
both slots of the drum clamp.
1
2
