B A C K PA N E L
28. Headphone output: Standard 1/4” headphone output connector.
29. Session/Mic switch: Used to assign the Session/Mic fader to either the
Session input or the MIC input.
30. Microphone input: 1/4” connector for connecting a microphone.
31. Phono Inputs: Phono level inputs for channels 1 and 2. Do not plug line
outputs into phono inputs.
32. Line inputs: Line level inputs for channels 1 and 2.
F R O N T PA N E L
33. Headphone output: Standard 1/8” (mini jack) headphone output
connector.
34. Reverse indicator LEDs: The LEDs indicate the status of the fader
reverse functions. The respective LED lights up when a fader is reversed.
35. Line fader curve switch: Three-position switch selects between a sharp,
mid and long fade for the corresponding line fader.
36. Cross fader curve switch: Three-position switch selects between a sharp,
mid and long fade for the crossfader.
37. Headphone output: Standard 1/4” headphone output connector.
34 34 34
35 36 35 33 37
