19
Specifications
Additional Information
TV system:
Depending on your country selection:
B/G/H. D/K
Colour system:
PAL, SECAM
NTSC 3.58, 4.43 (only Video In)
Channel Coverage:
VHF:
E2-E12
UHF: E21-E69
CATV: S1-S20
HYPER: S21-S41
D/K R1-R12, R21-R69
Picture Tube:
Flat Display FD Trinitron:
29” (approx. 73 cm. measured diagonally)
Rear Terminals
1/ 21-pin scart connector (CENELEC
standard) including
audio/video input,
RGB input, TV audio/video output.
2/ 21-pin Scart connector (CENELEC
(SMARTLINK) standard) including audio / video input, S
video input, selectable audio / video output
and Smartlink interface.
Audio outputs (Left/Right) - phono jacks
Side Terminals
3 S Video input – 4 pin DIN
3 video input – phono jack
3 audio input – phono jacks
headphones jack
S
S
Sound Output:
2 x 14 W (music power)
2 x 7 W (RMS)
Power Consumption:
94 W
Standby Power Consumption:
0.5 W
Dimensions (w x h x d):
Approx. 771 x 592 x 553 mm.
Weight:
Approx. 49 Kg.
Accessories supplied:
1 Remote Control (RM-947)
2 Batteries (IEC designated, AA/R6 size)
Other features:
• Teletext, Fastext, TOPtext
• Sleep Timer
• Smartlink (direct link between your TV set and a
compatible VCR. For more information on Smartlink,
please refer to the Instruction Manual of your VCR).
• Dolby Virtual.
Design and specifications are subject to change without notice
Ecological Paper - Totally Chlorine Free
