Outside Air Gate & Duct Kit
Cat. No. Model No. Description
H3991 OAK-UVFRC Outside Air Gate & Duct Kit
Outside Air Gate & Duct Kit
These kits have an air gate assembly, 4" diam-
eter duct and a termination hood. The air gate
allows adjustment of the amount of outside air
delivered to the fi re for combustion. Only one
kit, located on the right side of the fi replace,
is required.
(ref. Form #750,206M)
Blower Kit
The FBK-100 blower provides for a constant velocity forced air circulation feature for your ap-
pliance. The FBK-200 assembly with variable speed wall switch provides a forced air circulation
feature for your appliance.
Charcoal Canopy
Cat. # Model Models Where Used
H1989 FC36 UVFRC-3628, UVFRC-3628-H
(UVF-36 standard part)
H1990 FC42 UVFRC-4228 & UVFRC-4228-H
* Forced Air Blower Kits
Cat.
No.
Model No. Description
80L84 FBK-100 Blower, Standard
(single speed)
80L85 FBK-200 Blower, Variable Speed
(w/wall-mounted switch)
94L89 FBK-100-36 Blower, Standard, 36 Pack
94L90 FBK-200-36 Blower Kit - Variable Speed
with Wall Switch 36 Pack
(ref. Form # 750,028M)
Touch-Up Paint Kit
Repair of minor scratches and
discoloration of the appliance
charcoal painted surfaces may be
accomplished with the touch-up
paint kit.
Touch-Up Paint Kits
Cat. No. Model No. Description
90L74 TPK-C Touch-Up Paint (Charcoal)
(ref. Form # 504,216M)
PA I N T
The variable speed control
rheostat is included with
FBK-200 models only
An ON/OFF wall switch can be used
with the FBK-100 models (fi eld
supplied or order P/N 85L87 Wall
Switch Kit, shown below)
ON/OFF Wall Switch Kit
The ON/OFF wall switch kit
may be used to control the
blower operation, if FBK-
100 blower kit is installed.
Install the ON/OFF wall
switch in a convenient
location near the fi replace.
White Wall Switch Kit
Cat. No. Model No. Description
85L87 FWSK ON/OFF Wall Switch Kit
* The installation of these kits also require a Junction Box / Electrical
Kit, not included. See ordering information below
(ref. Form #750,195M)
(ref. Form #850,021M)
APPROVED ACCESSORIES AND
COMPONENTS
VENT-FREE GAS LOG SETS - MANUAL / PIEZO IGNITION, STANDING PILOT
Cat. # Model Description BTU/hr Input Models Where Used
H2126 VFGL18-MSN-4 18” Vent-Free Gas Log Set, Natural 14,000 - 25,000 UVF-36, UVFRC-3628 & UVFRC-3628-H
H2127 VFGL18-MSP-4 18” Vent-Free Gas Log Set, Propane 14,000 - 25,000 UVF-36, UVFRC-3628, UVFRC-3628-H
H2128 VFGL24-MSN-4 24” Vent-Free Gas Log Set, Natural 17,000 - 32,000 UVF-36, UVFRC-3628 & UVFRC-3628-H
H2129 VFGL24-MSP-4 24” Vent-Free Gas Log Set, Propane 17,000 - 32,000 UVF-36, UVFRC-3628 & UVFRC-3628-H
H2130 VFGL28-MSN-4 28” Vent-Free Gas Log Set, Natural 17,000 - 32,000 UVFRC-4228 & UVFRC-4228-H
H2131 VFGL28-MSP-4 28” Vent-Free Gas Log Set, Propane 17,000 - 32,000 UVFRC-4228 & UVFRC-4228-H
SERENE HEAT ® VENT-FREE GAS LOG SETS - MANUAL / PIEZO IGNITION, STANDING PILOT
Cat. # Model Description BTU/hr Input Models Where Used
H2053 SHGL-18MN-R 18” Vent-Free Gas Log Set, Natural 25,000 - 36,000 UVF-36, UVFRC-3628 & UVFRC-3628-H
H2054 SHGL-18MP-R 18” Vent-Free Gas Log Set, Propane 27,000 - 36,000 UVF-36, UVFRC-3628 & UVFRC-3628-H
H2055 SHGL-24MN-R 24” Vent-Free Gas Log Set, Natural 26,000 - 39,000 UVF-36, UVFRC-3628 & UVFRC-3628-H
H2056 SHGL-24MP-R 24” Vent-Free Gas Log Set, Propane 31,000 - 39,000 UVF-36, UVFRC-3628 & UVFRC-3628-H
(ref. Form #903,623M)
