Black & White Pinhole Board Camera
with Housing and Mounting Bracket
Specifications
Resolution
. . . . . . . . . . . . . . . . .
420 lines
Image Device
. . . . . . . . . . . . . . . .
1/3” CCD sensor
Minimum Illumination
. . . . . . . . . .
0.5 lux
Lens
. . . . . . . . . . . . . . . . . . . . .
3.6mm conical pinhole
Electronic Shutter
. . . . . . . . . . . . .
Auto 1/60 second to 1/100,000 second
Number of Pixels
. . . . . . . . . . . . .
512 H x 492 V picture elements
Operating Temperature
. . . . . . . . .
14°F to 122°F
Humidity
. . . . . . . . . . . . . . . . . .
Within 95% RH
Output Connections
. . . . . . . . . . .
Video-BNC, Power DC jack
Scanning System
. . . . . . . . . . . . .
EIA standard 525 TV lines 60 fields/sec.
Video Output Level
. . . . . . . . . . . .
1.0 Vp-p, 75 ohms composite, BNC connector
Video S/N Ratio
. . . . . . . . . . . . . .
Greater than 48dB
Synchronization System
. . . . . . . . .
Internal
Power Requirements
. . . . . . . . . . .
12 Volts DC @ 130mA
Dimensions
. . . . . . . . . . . . . . . . .
1 3/8” x 1 3/8”
Weight
. . . . . . . . . . . . . . . . . . . .
1.1 oz.
Suggested Power Supply
. . . . . . . . .
Speco Technologies PSW-2 or PSW-5
Specifications subject to change
For more information contact us at:
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
Features
Our high performance 1/3” black & white pinhole camera has a 0.5 lux sensitivity with a
420 line resolution. It features a 3.6mm conical pinhole lens with built-in electronic iris
and uses a BNC video output with DC power jack. A color version is available under model
number CVC-770PH.
