1. VALET MODE – The Immobilizer automatically arms 30 seconds

after the engine is turned OFF. However there may be certain

times (for repair or if the Touchkeys are lost, for instance) that
arming the Immobilizer is not desired. Note: When in the

valet/override mode, the LED flashes while the ignition is turned
OFF to help deter thieves. When the ignition is turned ON, the LED
will turn OFF.

2. EMERGENCY DISARM – If the Touchkey is lost, the engine will not

start, even with the proper car keys. In this case, the Immobilizer
must be put into the valet/override mode using the emergency

disarm procedure.

3. EMERGENCY DISARM/VALET MODE

Note: Immobilizer must be armed before you can enter your PIN.

a. Know the secret PIN. For the following example, assume the

PIN is 503. Note: Count 10 flashes for the number “0”.

b. While the LED is flashing (because the Immobilizer is armed),

turn the ignition ON. The LED will show steady ON.

c. Turn the ignition OFF and the LED will start flashing. Count

the flashes. After the 5

flash, turn the ignition ON. The LED

will show steady ON again. (This is your PIN’s first digit—5.)

d. Turn the ignition OFF and count the flashes. After the 10th

flash, turn the ignition ON. The LED will show steady ON
again. (2nd digit, 0)

e. Turn the ignition OFF and count the flashes. After the 3rd

flash, turn the ignition ON. The LED will show steady ON
again. (3rd digit, 3)

f. At this point, the LED will show steady ON for 10 seconds then

OFF to indicate the Immobilizer is in the valet/override mode.

4. EXITING THE VALET/OVERRIDE MODE – Insert a valid Touchkey

into the receptacle. EXIT VALET/OVERRIDE MODE AS SOON
AS POSSIBLE TO PREVENT THEFT OF YOUR VEHICLE.

1. If power is ever removed from the Immobilizer and then restored, it

will return to the state prior to removing power (If armed when
power was removed, it returns armed. If disarmed when power is
removed, it remains disarmed.)

2. While driving (when the ignition switch is ON), if the main power is

cut to the Immobilizer, the car will continue to function normally.

1. NUMBER OF TOUCHKEYS – The Immobilizer comes factory

coded to the two Touchkeys included in the package. The unit can
learn the codes of up to 4 Touchkeys.
Note – This procedure deletes the existing Touchkey Codes.
Therefore, you must do this procedure for both existing and new
Touchkeys at the same time.

2. CODE LEARNING PROCEDURE

Note: Immobilizer must be armed before you can enter your PIN.

a. Add the digits ―55‖ to the end of your secret 3-digit PIN. (For

example, if the PIN is 503, the 5-digit code learning PIN
is 50355).

b. While the LED is flashing (indicating the Immobilizer is armed),

turn the ignition ON. The LED will turn steady ON.

c. Turn the ignition OFF and count the flashes. After the 5

flash, turn the ignition ON. The LED will be steady ON again.
(This is your PIN’s first digit—5.)

d. Turn the ignition OFF and count the flashes. After the 10th

flash, turn the ignition ON. The LED will be steady ON again.
Note: “0”=10 flashes (2nd digit, 0)

e. Turn the ignition OFF and count the flashes. After the 3rd

flash, turn the ignition ON. The LED will flash rapidly.
(3rd digit, 3)

f. Turn the ignition OFF and count the flashes. After the 5th

flash, turn the ignition ON. The LED will be OFF. (4th digit, 5)

g. Turn the ignition OFF and count the flashes. After the 5th

flash, turn the ignition ON. The LED will flash rapidly.
(5th digit, 5)

h. Leave the ignition key ON. Once the LED stops flashing,

insert a Touchkey into the receptacle within 10 seconds. The
LED will turn steady ON to show the Touchkey was

successfully learned. (Repeat for all touch keys.)

3. EXIT THE CODE LEARNING PROCEDURE – There are three

ways to do this:

a. Turn the ignition switch OFF.
b. Wait more than 10 seconds to insert a new Touchkey.

c. If memory is full (you try to learn a 5th Touchkey), the unit will

go into valet/override mode.

Note: If new codes are programmed, all of the existing Touchkeys
must also be re-programmed.

MISTAKES – If the PIN is incorrectly keyed in, simply start over

from the first digit. Ignore any digits that have already been
keyed in.

CODE LEARNING NEW TOUCHKEYS

VALET MODE and EMERGENCY DISARM

POWER DOWN AND POWER UP

TOUCHKEY IMMOBILIZER

SLI

762FP-ISS
