Schlage LINK WCW100 - Manual (Page 3)

Enrolling the Camera
Camera enrollment is done using the www.schlagelink.com web site. You must have an active account before enrolling the
camera.
1. Make sure Ethernet and power are not plugged in to the camera.
2. Log on to your account at
www.schlagelink.com .
3. Click the Cameras tab.
4. Click the Add Cameras link.
5. Follow the on-screen instructions.
Î When enrolling a wireless camera, DO NOT disconnect the Ethernet cable until instructed to do so on
the web site.
Modifying the Camera Settings
1. Log on to your account at www.schlagelink.com .
2. Click on the Cameras tab.
3. Click the Edit Settings button next to the camera you want to edit.
4. To modify the wireless settings, click the Setup Wireless button.
Rebooting the Camera
1. Unplug A/C power.
2. Unplug Ethernet (if necessary).
3. Reconnect A/C power.
4. Connect Ethernet cable (do this for both wired and wireless cameras).
5. For wireless camera, log on to your account at
www.schlagelink.com and click the Cameras tab, then click
Reconnect Wireless .
Moving the Camera to a Different Account
The camera cannot be enrolled in two accounts at the same time. To move the camera to a different account, you must
first remove the camera from one account, and then enroll it into the new account.
1. Login to your account at www.schlagelink.com .
2. Click Cameras .
3. Click Edit Cameras .
4. Click Remove next to the camera you want to move.
5. Follow the on-screen instructions for removal.
6. Once the camera is removed from the account, it can be added to a different account. See
Enrolling the Camera
for more information.
Lights
Light Light Behavior Description
Power Green Steady Power On
Off Power Off
Green Blinking Start Up
Network Green Steady Power On
Off Wireless or LAN not connected, or
camera is not sending/receiving data
Green Blinking Sending/receiving data
POWER
NETWORK
