1.34
LIST PARTS MAINFRAME LOWER
Item No. Description Part No.
617
Qty
619
Qty
Item Note
1 HOUSING GEARBOX BEARING RH 410047 0 1
2 CARRIER BLADE BOSS-DIE CAST 410078 1 1
3 HOUSING BEARING ROLLER 219102 2 2
4 BEARING FRONT AXLE 410069 2 2
5 VARIATOR 411001 0 1
6 CHAIN 40 PITCHES 3/8" INC LINK 111-0077 0 1
7 FRICTION DISC 410057W 1 1
8 GEARBOX 111-0804 0 1
9 HOUSING PIVOT BEARING RR AXLE 410048 1 1
10 PLATE SECURING 219037 1 1
11 SPRING COUNTER BALANCE 410050 1 1
12 SPROCKET 10T*3/8" 111-0123 0 1
13 SPROCKET 18T*3/8" 111-0122 0 1
14 AXLE FRONT WA 111-0027 1 1
15 CAST CHASSIS 111-0031 1 1
16 MOULDING FIN 111-0034 1 1
17 MOULDING SNAIL DECK 111-0037 1 1
18 MOULDING SNAIL DECK ACCESS 111-0038 1 1
19 MOULDING THROW PLATE 111-0039 1 1
20 CLUTCH LEVER 411020 0 1
21 MOUNT BEARING 111-0050 1 1
22 CUTTER BAR 111-0093 1 1
23 HOC KNOB RIGHT 111-0055 1 1
24 COVER ROLLER L.H. 111-0057 1 1
25 COVER ROLLER R.H. 111-0058 1 1
26 ROD CONNECTING 111-0063 1 1
27 WHEEL 111-2021 2 2
28 WHEEL CENTRE CAP 111-0066 2 2
29 PLATE SPRING MOUNT 111-0073 1 1
30 KEY WOODRUFF 1662 1 1
31 NUT M6 NYLOC 09438 1 2
32 SPRING 411021 0 1
33 BELT VARIATOR 411025 0 1
34 BELT VARIATOR 411024 0 1
35 NUT M8 NYL INSERT T TYPE 09441 1 2
36 SCREW PT M4*25 111-0100 15 15
37 BOLT M8*55 HEX 09565 1 1
38 TAPTITE M6*16 SCREW 09365 10 13
39 TAPTITE M6*20 SCREW 09575 2 2
40 TAPTITE M8*25 SCREW 09787 0 1
41 SCREW M4 HY100078 2 2
42 SCREW TAPTITE M6*16 C/SK POSI 09545 4 4
43 WASHER PLAIN 09262 1 1
44 ROLLER FRAME WA 111-0028 1 1
45 SPRING TORSION HOC GALVANISED 111-0078 1 1
