Connecting the microphone – Sennheiser e965 User Manual
Page 8
6
Connecting the microphone
̈
Use a microphone cable with XLR-3 female connector to
connect the microphone’s XLR-3 male connector
·
to the
microphone preamplifier. The microphone preamplifier must
provide 48 V phantom powering.
Pin assignment of the XLR-3 connector
1
2
3
1
2
3
+
+
1
2
3
XLR
6,3 mm
+
+
1
2
3
XLR
+
XLR
symmetrisch
XLR
+
e965_524141_0408_Sp6.book Seite 6 Mittwoch, 28. Mai 2008 11:14 11
