Fuses Usage
HVAC
BLOWER
HVAC Blower Motor
RH HDLP Right Headlamp
FRT WIPER Front Wiper
ETC (2.2L)
Engine Control Module (ECM),
Electronic Throttle Control
SUNROOF Sunroof Module
BRAKE Stop Lamps
IGN Ignition switch
IGN/INJ (L4),
ECM/
CAM (V6)
Engine Ignition Module, Fuel
Injectors (2.2L L4 (L61))
Camshaft Sensor, Main Relay
Voltage To PCM, Ignition Coils 1-6
INJECTORS
(3.5L V6 (L66))
Fuel Injection
Fuses Usage
PWR TRAIN
Engine Control Module (ECM),
Transmission Control Module
(TCM), Transmission
BACKUP
Low Coolant Switch, Backup Lamps
(2.2L L4 (L61)), Vehicle Speed
Sensor (Manual), Transmission
Range Switch (2.2L L4 (L61))
HTD SEATS Heated Seats
COOL LO (L4)/
COOL 2 (V6)
Cooling Fan Low (L4), Cooling
Fan (V6)
A/C CLUTCH
A/C Clutch, Back Up Lamps
(3.5L V6 (L66))
FUEL PUMP Fuel Pump
AUX 1
OUTLET
Front Auxiliary Power Outlet
PREM AUD Premium Radio Amplifier
ABS ABS Ignition
PWR SEAT Power Seats
5-97
