-32-
ref part # description ref part # description
57 X1676057 SUPPORT 5 ⁄
8
''-11 x 9''
58 X1676058 RUBBER FOOT
59
X1676059 IDLER ROLLER SHAFT
62A X1676062B ROLLER ADJ BAR
64 X1676064 IDLER ROLLER
69 X1676069 MITER BODY
69A X1676069A PHILLIPS ® SCREW 10-24 x 3 ⁄
4
"
69B X1676069B PIN 1 ⁄
4
"
70 X1676070 SCALE
71
X1676071 POWER CORD
77 XPAW04M ALLEN ® WRENCH 4MM
80 XPK23M KEY 5 X 5 X 25
81A X1676081A ROCKER ARM
82A X1676082A LEVER, SHORT
83A X1676083A ROCKER ARM
84A X1676084A ECCENTRIC
85A X1676085A
LEVER, LONG
86A X1676086A KNOB, 3 ⁄
8
"-16
87A X1676087A SPACER
88A XPB21
HEX BOLT 3 ⁄
8
"-16 x 3 ⁄
4
"
89 XPSB31 CAP SCREW 10-24 x 5 ⁄
8
"
90 X1676090 MOTOR CORD (1)
90A X1676090A MOTOR CORD (2)
91 XPB16 HEX BOLT 3 ⁄
8
"-16 x 1 1 ⁄
2
"
92 XPW02 FLAT WASHER 3 ⁄
8
"
93 X1676093 WASHER PLATE
94 X1676094 KNOB
95 XPLW01
LOCK WASHER 5 ⁄
16
"
96 XPSS18 SETSCREW 5 ⁄
16
"-18 x 3 ⁄
4
"
97 XPW07 FLAT WASHER 5 ⁄
16
"
98 XPN11 HEX NUT 3 ⁄
8
''-24
99 X1676099 GRAPHITE PAD
100 X1676100 DUST PORT ABS
101 X1676101 FLAT WASHER 3 ⁄
8
"
102 X1676102 DIRECTION SCALE
103 X1676103 POINTER
104 X1676104
LOGO
104A X1676104A LOGO SCREW
105 XPN08 HEX NUT 3 ⁄
8
"-16
106 X1676106 HEX NUT 10-24
107 X1676107 PHILLIPS ® SCREW 3 ⁄
16
"-24 X 3 ⁄
8
"
110 X1676110 CABINET
110A X1676110A CABINET DOOR
110B X1676110B DOOR LATCH SYSTEM
110C X1676110C SHELF
111 X1676111 SWITCH HOUSING
112 X1676112 READ MANUAL WARNING
113 X1676113 MACHINE ID/WARNING
114 X1676114 IDLER ROLLER GUARD
115 X1676115 LOCK KNOB
118 X1676118 PHILLIPS ® SCREW 3 ⁄
16
"-24 X 3 ⁄
8
"
119 X1676119 DUST PORT
120 X1676120 WIRE CONNECTOR 1 ⁄
2
"
121 X1676121 ELECTRICITY WARNING
122 X1676122 UNPLUG WARNING
123 X1676123 SAFETY GLASSES WARNING
01 X1676001 DUST COVER
02 XPR03M SNAP RING 12MM
02A XPR05M SNAP RING 15MM
03 X1676003 BEARING 6201-ZRS
03A X1676003A BEARING 6002-ZRS
04 X1676004
DRIVE SHAFT
05 X1676005 SANDING BELT 6'' X 48''
06 XPK02M KEY 5 X 5X 40
07 X1676007 SNAP RING 16MM
08 X1676008 SANDING BELT FRAME
09 X1676009 BACK STOP
10 XPSS02 SETSCREW 5 ⁄
16
"-18 x 3 ⁄
8
"
11 X1676011 DRIVE ROLLER
12 X1676012 HEX NUT 5 ⁄
16
"-18
13 X1676013 5 ⁄
16
" FLAT WASHER
14 X1676014 KNOB
15 X1676015 BEARING 6003-2RS
16 X1676016 COMPLETE MITER GAUGE ASSY
18 X1676018 CARRIAGE BOLT 5 ⁄
16
"-18 x 1 1 ⁄
4
"
19 X1676019 PULLEY COVER
20 X1676020 MITER BAR
20A X1676020A STUD 1 ⁄
4
"
21 X1676021 CAST IRON DISC 10''
22 X1676022 SANDING DISC PAPER 10"
23 X1676023 TABLE
24 X1676024 TRUNNION
25 XPW06
FLAT WASHER 1 ⁄
4
"
26 XPS04 PHILLIPS ® SCREW 1 ⁄
4
"-20 X 1 ⁄
2
"
27 X1676027 PHILLIPS ® SCREW 10-24 X 1 ⁄
4
"
27A X1676027A PHILLIPS ® SCREW 10-24 X 3 ⁄
8
"
27B X1676027B FLAT WASHER 3 ⁄
16
"
28 X1676028 TABLE POINTER
28A X1676028A MITER POINTER
28B X1676028B LOCK BRACKET
28C X1676028C LOCK PIN
29 X1676029
TABLE SUPPORT BRACKET
30 X1676030 SUPPORT BAR
32 XPB09 HEX BOLT 5 ⁄
16
"-18 x 1 ⁄
2
"
33 X1676033 TABLE MOUNT
34 X1676034 V-BELT 3L-240
35 X1676035 PULLEY
36 X1676036
MOTOR PULLEY
37 X1676037 KNOB
40 X1676040 BRACKET
41 XPB03
HEX BOLT 5 ⁄
16
"-18 x 1"
42 XPSS03 SETSCREW 5 ⁄
16
"-18 x 1 ⁄
4
"
43 X1676043 MOTOR
44 X1676044
LOCK KNOB
45 X1676045 PLASTIC WASHER 1 ⁄
4
"
46 X1676046 FLAT WASHER 3 ⁄
16
"
49 X1676049 STRAIN RELIEF FITTINGS
51 X1676051 HEX NUT 10-24
52 X1676052 BASE
53 X1676053
SWITCH LOCK
53A X1676053A SWITCH
56 XPN04
HEX NUT 5 ⁄
8
''-11
parts
