Crankshaft & pistons – Shibaura S773L User Manual
Page 27
101741 05/09
3-9
Crankshaft & Pistons
NOTES:
1. Item 1 includes (items 2, 3 and 4).
2. Item 5 includes (items 8 and11).
3. Item 6 includes (items 8 and 11).
4. Item 7 includes (items 8 and 12).
5. Item 15 includes (item 16).
6. Item 19 includes (items 20, 21, and 22).
ITEM NO.
SERVICE
PART NO.
QTY.
DESCRIPTION
1
115256830
1
CRANK SHAFT COMPL
2
115276180
1
CRANK SHAFT GEAR
3
030300816
1
SPRING PIN
4
030509020
1
DOWEL PIN
5
110156400
1
BEARING HOLDER ASSEMBLY G.1 (NOT SHOWN)
6
110156410
1
BEARING HOLDER ASSEMBLY G.2 (NOT SHOWN)
7
110156420
1
BEARING HOLDER ASSEMBLY G.3 (NOT SHOWN)
8
030500612
6
DOWEL PIN
9
198517572
3
METAL ; UPPER S.T.D.
198517576
3
METAL ; UPPER U.S. 0.25
198517579
3
METAL ; UPPER U.S. 0.50
10
198517582
3
METAL ; LOWER S.T.D
198517586
3
METAL ; LOWER U.S. 0.25
198517589
3
METAL ; LOWER U.S. 0.50
11
010810840
4
BOLT
12
010810845
2
BOLT
13
011510850
2
BOLT
14
010700845
2
BOLT
15
115017610
3
PISTON KIT S.T.D.
16
115107240
3
PISTON RING KIT S.T.D.
17
115326231
3
PISTON PIN
18
036500021
6
SNAP RING
19
115026340
3
CONNECTING ROD ASSEMBLY (NOT SHOWN)
20
198517125
3
BUSHING
21
115176150
6
CONNECTING ROD BOLT
22
198517602
6
METAL S.T.D.
198517606
6
METAL S.T.D. 0.25
198517609
6
METAL S.T.D. 0.50
23
020109075
6
NUT
