Sega GAME SHOW - Manual (Page 30)

22 www.seuservice.com
SuperBall Bin (P 1/1)
Item Num-
ber
Part Number Description Picture
1 999-2048 Ball Bin
2 999-2056 Stirer Holddown Ring
3 999-2060
Superball Stirer Short
Spring
4 999-2061
Superball Stirer Long
Spring
5 999-2057 Superball Stirer Guide
6 999-2058 Superball Stirer Body
7 999-2059 Superball Stirer
NOTE: To access the Superball bin, you need to reach
in through the coin door and unlatch the two latches
located on the right and left insides located infront of the
bin. After unsecuring these latches the yellow rest area
can be raised up and pulled forward to remove. Then
the Superball bin can be lifted out.
NOTE: Ballhole goes on the right side looking into the
bin on reassembly.
