Congratulations on your choice of the Stanton RM-22 Professional
DJ Mixer. You now own one of the most flexible DJ mixers ever
designed. The rackmountable RM-22 offers up to three Microphone
inputs, three Phono inputs and nine Line inputs—making it one of
the most powerful DJ mixers around. And with Stanton’s smooth
fader movement and rock-solid reliability, it’s the perfect mixer for
mobile and club DJs alike.
Please take a moment to familiarize yourself with the RM-22 by
reading through this Owner ’s Manual. (And don’t worry—we’ll make
it quick so you can start mixing!)
Welcome
The RM-22 is an extremely versatile mixer with enough inputs to
accommodate many DJ setups including multiple turntables, CD
players and microphones. Below we list some of the RM-22’s most
salient features (in case you forgot already!):
• 19” rackmountable DJ mixer with connections for multiple
turntables, CD players and microphones
• 4-channel design with assignable crossfader for mixing a variety
of sources
• Individual gain control per channel with clip LED for setting
optimum levels
• Easy monitoring via PFL switches and headphone mix with
Split Cue and Cue Pan functions.
• Fader Start buttons for controlling compatible CD players like
Stanton S-Series
• Dual 7-band Master EQ for tweaking mixes to suit different venues
• Mic inputs 1 and 2 feature 2-band EQ and handy Talkover function
• Individual outputs and level control for Master, Zone and Booth
Technical Specifications
Frequency Response
THD+N (Line)
Signal to Noise Ratio
(ref: max level)
Noise
Crosstalk
(Line to Line, Phono to
Line, Line to Phono)
Fader Kill
Microphone EQ
Graphic EQ (7 band
stereo)
Line Inputs
Phono Inputs
Phono / CD
Mic Inputs
Master Outputs
Zone Output
Booth Output
Record Output
Headphone Output
Dimensions (LxWxD)
Weight
20 Hz to 20 kHz +1 dB
> 0.005 % at 1 kHz
> 109 dB (main signal path)
-98 dBV (Line input to any output)
> -90 dB
> -90 dB
Hi, Low +12 dB
40 Hz, 80 Hz, 160 Hz, 500 Hz,
1.6 kHz, 3.2 kHz, 6.4 kHz + 10 dB
7(RCA) , 1(1/4” Balanced) -10 dBV / >10 kOhm
2 (RCA), -50 dBV / 47 kOhm
2 (RCA), -50 dBV (Phono) -10 dBV (Line) / 47
kOhm
2 (1/4”), 1 (XLR) -50 dBV / 2.4 kOhm
2 (1/4”) Balanced/ (RCA) unbalanced,
+4 dBu balanced / -10 dBV unbalanced
2 (RCA) unbalanced / -10 dBV
2 (RCA) unbalanced / -10 dBV
2 (RCA) unbalanced / -10 dBV
1 (1/4 inch), 1 (1/8 inch) greater than 32 Ohm load
18.9 in. x 8.66 in. x 4.72 in. (48 cm. x 22 cm. x 12
cm.)
4.5 kg (9.9 lbs)
RM-22 Features
