Speco Technologies CVC6146SCSW User Manual
Indoor dome with 2.8-12mm lens, Features, Specifications

Speco Control Series Cameras
with Full On-Screen Display Functions
For more information contact us at:
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
Features
Full OSD control of all major camera functions:
• Lens type* – DC auto iris or manual: Controls brightness of DC auto iris lenses
• Shutter type* – Manual, fixed, flickerless or auto
• BLC – Adjustable sensing area of 100 points on the screen: Adjustment of BLC ratio
• AGC – On/Off: Adjustability of AGC amount from 0 to 255
• White Balance – ATW, AWB, Fixed (pre-sets) or complete manual control of Reds & Blues
• Camera Titles – On/Off: Easy user set-up
• Day/Night – Auto / Color / B&W
• Mirror Image – To reverse field of view
• Privacy Screens – Easy user set-up and dynamic control for exact settings
• Adjustability of several other camera functions including Contrast, Sharpness, CB-gain, CR-gain, etc.
*Not needed on certain SCS models
Specifications
Image Pick-Up Device
. . . . . . . . . . . . . .
1/3” Sony Super-HAD
™
CCD
Effective Pixels
. . . . . . . . . . . . . . . . . .
768(H) x 494(V)
Resolution
. . . . . . . . . . . . . . . . . . . . .
550 TV line
Minimum Illumination
. . . . . . . . . . . . . .
0.5 lux
Scanning System
. . . . . . . . . . . . . . . . .
2:1 Interlace
Synchronization
. . . . . . . . . . . . . . . . . .
Internal
S/N Ratio
. . . . . . . . . . . . . . . . . . . . . .
More than 50dB
Power Requirement
. . . . . . . . . . . . . . . .
12 Volts DC/24 Volts AC Dual Voltage
Dimensions
. . . . . . . . . . . . . . . . . . . . .
5.5” W x 4.5” H
Cameras come with mounting hardware
CVC6146SCS
CVC6146SCSW
(white)
Indoor Dome with 2.8-12mm Lens
Optional Accessories (Sold Separately):
7246WMT
Weatherproof wall mount for use with many Speco Dome Cameras
BCP
Corner/pole mount for use with many Speco Dome Cameras
DFM1 / DFM2
Recessed Ceiling mounts for use with many Speco Dome Cameras
Speco Technologies is constantly developing product improvements.
We reserve the right to modify product design and specifications without notice and without incurring any obligation.
Rev. 1/27/10
