15
Bearing Kit Parts
B = Blue Loctite required
Part #
1.a
1.b
1.c
1.d
1.e
1.f
1.g
1.h
Qty.
2
4
2
2
2
6
2
4
Part Description
BB Pivot Bearing
Dropout Pivot Bearing
S-Link @ Frame Pivot Bearing
S-Link @ Seatstay Pivot Bearing
BB Pivot Spacer
Dropout Pivot Bearing Spacer
S-Link @ Frame Pivot Spacer
S-Link @ Seatstay Pivot Spacer
Part Specification
6802 RS (Orange) Series Full Complement Bearing - 24mm O.D. x 15mm I.D. x 5mm Width
6800-2RS Series Bearing - 19mm O.D. x 10mm I.D. x 5mm Width
6802 RS (Orange) Series Full Complement Bearing - 24mm O.D. x 15mm I.D. x 5mm Width
6800V-2RS (Orange) Series Full Complement Bearing - 19mm O.D. x 10mm I.D. x 5mm Width
Alloy spacer - 19.0mm O.D. x 15.1mm I.D. x 4.0mm Width
Alloy spacer - 16.0mm O.D. x 10.1mm I.D. x 2.0mm Width, Chamfered
Alloy spacer - 19.8mm O.D. x 15.1mm I.D. x 4.0mm Width, Chamfered
Alloy spacer - 16.0mm O.D. x 10.1mm I.D. x 2.0mm Width, Chamfered
Torque in*lb Part Specification Part # Qty. Part Description
2.a
2.b
2.c
2.d
2.e
2.f
2.g
2.h
2.k
Alloy Axle - M15 Thread (23.5mm Head O.D.) x 67.5mm Shaft Length, 8mm Allen Hex Head
Alloy Nut - M15 Thread x 23.5mm O.D, 19mm socket (use 6-point 19mm socket only)
Alloy Bolt - M10 Thread x 28mm Shaft Length, 4mm Allen Hex Head
Alloy Axle - M15 Thread x 28mm Shaft Length, 8mm Allen Hex Head
Alloy Bolt - M10 Thread x 19.5mm Shaft Length, 4mm Allen Hex Countersunk Head
Alloy Bolt - M8 Thread x 33.5mm Shaft Length, 4mm Allen Hex Head
Alloy Nut - M8 Thread x 16.5mm O.D, 12mm Socket
Steel Washer - 16.5mm O.D x 8.1mm I.D. x 0.5mm Thick
Steel Bolt - M8 Thread x 40mm Shaft Length, 6mm Allen Hex Head
BB Pivot Axle
BB Pivot Nut
Dropout Pivot Bolt
S-Link @ Frame Pivot Bolt
S-Link @ Seatstay Pivot Bolt
Lower Shock Eye Bolt
Lower Shock Eye Nut
Lower Shock Eye Washer
Upper Shock Eye Bolt
1
1
2
2
2
1
1
2
1
200-230 B
200-230
120-140 B
200-230 B
120-140 B
70-90 B
70-90 B
70-90
NOTE: Bearing and Bolt Kits are available only through your local Specialized dealer. To retain your warranty and for your safety, all
maintenance should be performed by your local Specialized dealer.
Bolt Kit Parts
