Sterling Mobility Scooter - Manual (Page 17)

1 4 Iss 4
Safety warning and user guidance
Lifting heavy or bulky components
Seat:
1. Lift armrests upwards until vertical (Photo 2).
2. Stand behind seat and fold the backrest down (Photo 3).
3. Hold the seat rotation lever upwards.
4. Carefully remove the seat, keeping your back straight and bending your
knees.
5. Place seat at desired location for stowage, keeping back posture
straight at all times, bend knees where required.
Batteries:
1. Remove the seat.
2. Remove left battery pack first (Photo 1+2). Then remove the right
battery pack. Take note of the instruction on the yellow triangular label.
3. To replace the battery packs install the right battery pack first and then
the left. Take note of the instruction on the yellow triangular label (Photo
3).
4. The battery packs must be engaged together before driving (Photo 4).
Photo 3
Photo 2
Photo 4
Photo 1
