Southbend SB1040 - Manual (Page 69)

For Machines Mfg. Since 8/09 Model SB1040/SB1041
-67-
W A R R A N T Y
Made in Taiwan to South Bend Specifications
Motor: 1HP, 220V, 3-Phase
Amps: 3A
Blade Width Range: 1/8"–5/8"
Blade Length: 139-3/8"–140-1/2"
Blade Speeds: 88–384 FPM
Maximum Cutting Height: 9-5/8"
Capacity Left of Blade: 17-9/16"
Weight: 803 Lbs.
1. Read and understand manual before star ting.
2. Always wear safety glasses or a face shield.
3. Never place hands directly in “line of cut.”
4. Keep all guards in place and correctly adjusted.
5. DO NOT wear loose clothing, gloves, or jewelry. Secure
long hair and button all long sleeve shir ts.
6. Disconnect power before performing maintenance, service, or adjustments.
7. Ensure machine is properly installed, set up, and adjusted before star ting.
8. DO NOT operate when tired, or under the influence of
drugs or alcohol. 9. Never attempt to stop the blade with your hand or work-
piece; allow the blade to stop on its own. 10. DO NOT force or twist blade when cutting.
11. Use fixtures, not your hands, to hold small or round
workpieces.
12. DO NOT back workpiece away when blade is moving. Turn
saw off and wait for the blade to come to a complete stop. 13. Never leave this machine running attended.
TO REDUCE THE RISK OF SERIOUS PERSONAL INJURY WHILE
USING THIS MACHINE:
WARNING! !
MODEL SB1041
18" VARIABLE SPEED
METAL CUTTING BANDSAW
MFG Date:
Serial No:
WARNING! !
INJURY HAZARD!
Keep door closed
while machine is
operating. Disconnect
power before opening
door. INJURY HAZARD
Do not use machine if
you have not read the
manual. Visit
southbendlathe.com or
call 360-734-1540 to
get a manual.
WARNING! !
EYE INJURY HAZARD
Always wear ANSI-
approved safety
glasses or a face shield
when using this
equipment.
WARNING! !
WARNING! !
! INJURY/SHOCK
HAZARD
To avoid shock or
accidental star ting,
disconnect power
before adjusting or
servicing machine.
WARNING! !
CUTTING HAZARD
Always keep hands
and body away
from blade when
machine is running.
UNSTABLE WORKPIECE
HAZARD!
WARNING! !
Workpieces that cannot be suppor ted or stablized
without a vise or jig should not be cut on a ver tical
metal-cutting bandsaw. Such workpieces can
unexpectedly move while cutting and draw the
operator’s hands into the blade, causing serious
personal injury. Examples are chains, cables, round
or oblong-shaped workpieces, workpieces with
internal or built-in moving or rotating par ts, etc.
NOTICE
Only change
speeds when the
machine is running.
SL
OW
SP
EED FA
ST
WARNING! !
! INJURY/SHOCK
HAZARD
To avoid shock or
accidental star ting,
disconnect power
before adjusting or
servicing machine.
WARNING! !
INJURY HAZARD!
Keep door closed
while machine is
operating. Disconnect
power before opening
door.
SB 04
701
702
703
704
705
706
707
708
709
710
711
712
713
706
703
Machine Labels
The safety labels provided with your machine are used to make the operator aware of the
machine hazards and ways to prevent injury. The owner of this machine MUST maintain the
original location and readability of these safety labels. If any label is removed or becomes
unreadable, REPLACE that label before using the machine again. Contact South Bend Lathe Co. at
(360) 734-1540 or www.southbendlathe.com to order new labels.
REF PART # DESCRIPTION REF PART # DESCRIPTION
701 PSBLABEL09VL EYE INJURY HAZARD LABEL 708 PSBLABEL15L ELECTRICITY LABEL
702 PSBLABEL01VL READ MANUAL LABEL 709 PSBLABEL14HL CUTTING HAZARD LABEL
703 PSBLABEL14VS CLOSE DOOR WARNING LABEL 710 PSB1040710 MODEL NUMBER LABEL (SB1040)
704 PSB1040704 MACHINE ID LABEL (SB1040) 710 PSB1041710 MODEL NUMBER LABEL (SB1041)
704 PSB1041704 MACHINE ID LABEL (SB1041) 711 PSBPAINT01 SB GRAY TOUCH-UP PAINT
705 PSB1040705 UNSTABLE WORKPIECE LABEL 712 PSB1040712 SPEED DIRECTION LABEL
706 PSBLABEL02HL SHOCK HAZARD LABEL 713 PSB1040713 CHANGE SPEED NOTICE LABEL
707 PSBLABEL18 ALLEN BRADLEY CONTROLS LABEL
