TECHNICAL SPECIFICATIONS SMC2582W-B / SMCPWR-INJ3
STANDARDS
• IEEE802.11b, IEEE802.1x,
• IEEE802.3, IEEE802.3u, IEEE802.3af
INTERFACE
• 1x 10BASE-T/100BASE-TX (RJ-45) Port
• 1x RS-232c Serial Port
• IEEE802.11b Wireless LAN
MEDIA ACCESS PROTOCOL
• CSMA/CA
OPERATIONAL MODE
• Infrastructure Mode
• Access Point/WDS Bridge (used in pure
SMC2582W-B bridging environment)
• Bridge Master/Slave (used when
SMC2586W-G, SMC2582W-B, and
SMC2682W are in the bridging environment)
TRANSFER DATA RATES
• 11, 5.5, 2, 1 Mbps with auto-Fallback
MODULATION TYPE
• IEEE802.11b: DSSS
Modulation Data Rate
DBPSK 1 Mbps
DQPSK 2 Mbps
CCK 5.5, 11 Mbps
CHANNELS/FREQUENCY RANGE
• 2.4 GHz frequency band
• 11 channels, 2.400 ~ 2.4720 GHz
(US, Canada)
• 13 channels, 2.400 ~ 2.4835 GHz (ETSI)
• 14 channels, 2.400 ~ 2.4970 GHz (Japan)
TRANSMIT OUTPUT POWER (E.I.R.P.)
Transmit Power Control IEEE802.11b
High 16-18 dBm
Medium High 13-15 dBm
Medium 10-12 dBm
Medium Low 7-9 dBm
Low 4-6 dBm
RECEIVE SENSITIVITY
Transfer Rate IEEE802.11b
1 Mbps -91 dBm
2 Mbps -88 dBm
5.5 Mbps -85 dBm
11 Mbps -83 dBm
ANTENNA TYPE
• One removable, replaceable 2 dBi Antenna
• R-SMA (male) connector for external
Antenna
OPERATING RANGE
• 802.11b: up to 457m/ 1.500 ft
• Ranges vary based upon numerous
environmental factors so individual
performance may be significantly different.
SECURITY
• 64-/128-bit WEP encryption
• TKIP encryption
• Wi-Fi Protected Access (WPA)
• IEEE802.1x, EAP-MD5, EAP-TLS,
EAP-TTLS, PEAP, LEAP
• Disable SSID Broadcast
• MAC address filtering
• Wireless Client Isolation
CONFIGURATION AND MANAGEMENT
• Web-browser, Telnet, TFTP, SNMP
• Syslog, Event Logging
• DHCP Server
MAXIMUM CLIENTS
• 64
LED
• Power, LAN, WLAN, Alive
TEMPERATURE
• Operating: 0°C ~ 55°C / 32°F ~ 131°F
• Storage: -20°C ~ 70°C / -4°F ~ 158°F
HUMIDITY (NON-CONDENSING)
• 5% ~ 95% in storage
DIMENSION (WITHOUT ANTENNAS)
• 172 x 140 x 32 mm / 6.75 x 5.5 x 1.25 in
WEIGHT
• 363 g/ 0.80 lbs
COMPLIANCE
• Wi-Fi compliant
• FCC Part 15 Class B
• IC (Canada)
• ETSI, EN300328-1/ EN300328-2/
EN60950/EN301489-1/-17 (Europe)
WARRANTY
• Limited Lifetime
SMCPWR-INJ3 (optional)
INPUT POWER REQUIREMENTS
• AC Input Voltage: 90 - 264VAC, 47-63 Hz
• AC Input Current: 2A at 100VAC, 1A at
240VAC (-48VDC)
OUTPUT VOLTAGE
• Aggregate Power: 50W (48VDC)
PoE OUTPUT SPECIFICATION
• PIN Assignments and Polarity:
(+) 4/5, (-) 7/8
LEDs
• AC Power, Power Active, Over Current
Protection, Connectors Shielded RJ-45
TEMPERATURE
• Operating: 0°C ~ 40°C / 32°F ~ 104°F
• Storage: -25°C ~ 85°C / -13°F ~ 185°F
HUMIDITY (NON-CONDENSING)
• Max. 90% in storage
DIMENSION
• 101 x 140 x 38 mm/ 4 x 5.5 x 1.5 in
WEIGHT
• 626 g / 1.38 lbs
COMPLIANCE
• FCC Part 15 Class B
• CE
• UL1950
• CSA A22.2 No. 950
• EN60950
• CB
