Perform the following procedures 1 to 4 to hook up your system using the supplied cords and
accessories.
1 Connect the speakers.
Connect the right and left speaker cords to
the SPEAKER terminals as shown below.
2 Connect the FM and AM aerials.
Set up the AM loop aerial, then connect it.
Plug type A
Getting Started
Hooking up the system
4
2
3
1
AM loop aerial
Right speaker Left speaker
FM lead aerial
L
#
R
SPEAKE
R
IMPED
ANCE
USE 6-16
Ω
#
3
3
Red (3)
Insert this portion
Black (#)
ANTEN
NA AM
FM 75
AM loop
aerial
Extend the FM lead aerial horizontally
