background image

Item #

Description

Part #

1

Grass Chute

(CH5) 6031TK

Bolt/Nut

(CH5B) NB136

Spring

CH5S

2

Tire/Wheel/Bearing

F4157W

3

Right Belt Guard

6155RN

Acorn Nut

(FR154N) NB120

4

Battery Cable Red

BCSR

Battery Cable Black

BCS

5

Height Adjust Crank Assembly

H7ASY

Height Adjust Crank

H7N

Plastic Bushing

T2PB

Cotter Pin

(T218C) NB580

Knob

H7K

5/16 Pal Washer

NB117

Threaded Link to the Deck (Not

included in Hgt Adj Assembly)

(674S) 10038

6

Left Belt Guard

6155LN

Acorn Nut

(FR154N) NB120

7

Gas Tank

6102T

Gas Cap

6102NC

Gas Tank Mount

6102TK

Rubber Bushing

AS119

Fuel Shutoff Valve

AS120

Fuel Line Clamp

6FLC

Fuel Line

6102FLN

8

Height Adjust Crank Assembly

H7ASY

Height Adjust Crank

H7N

Plastic Bushing

T2PB

Cotter Pin

(T218C) NB580

Knob

H7K

5/16 Pal Washer

NB117

Threaded Link to the Deck (Not

included in Hgt Adj Assembly)

(674S) 6599

9

Tire/Wheel/Bearing

F4157WF

Bolt/Nut

(670/T2K) NB151/NB121

Spacer (Exterior)

663S

Spacer (Exterior)

663L

Spacer (Interior)

691

10

Caster Fork

665TK

Caster Nut

(665N) NB122

Washer Upper

(665TW) NB195

Washer Lower

(665BW) NB195

18
