Onnection, Iagrams – Sony Ericsson DVP-CX777ES User Manual
Page 2
2 of 4
C
ONNECTION
D
IAGRAMS
B
ILL
O
F
M
ATERIALS
#
Device
Manufacturer
Part Number
Protocol
Connector Type
Notes
1
DB9F to RJ45 NULL Adapter
HomeLogic
HA-CB-328
RS-232
DB-9 Female X RJ-45 Female
2
Cat5 Cable Assy.
Installer
N/A
RS-232
RJ-45 Male X Wire
3
Network Assembly
HomeLogic
HW-NA-18X4
RS-232
RJ-45 Female X DB-9 Female / USB
4
HomeBrick
HomeLogic
HW-HB-1080
RS-232
DB9 Male / USB
