Sanyo DSR-2004 - Manual (Page 2)

CCTV monitor
Not compatible with VSP controllers
VGA monitor
VGA or Analog
monitor selection
switch
To 12 V DC
power supply
(AC adaptor
packaged)
Four cameras
Four sensor
inputs
LAN for
connection to
the Digital Client
Line in
Line out
Alarm output
NTSC/PAL switch
Warnings regarding HDDs
• Do not attempt to install or replace a HDD on your own. You cannot use these HDDs on PCs.
• The unit may be damaged if it is exposed to an impact or vibration, or the power plug is disconnected during operation.
• Sanyo will not be held liable for any data loss due to an HDD error or a failure during recording.
* “Microsoft” is registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
* All other company and product names are registered trademarks and/or trademarks of their respective owners.
NOTE: Specifications subject to change without notice
Max HDD Capacity 500GB
MPEG-4
3 levels (Basic, Normal, Fine)
4
English / French / German / Spanish / Italian / Russian / Chinese / Polish /
Czech / Swedish / Rumanian / Bulgarian / Serbian / Japanese
SANYO (H-SSP) / PELCO-D / KALATEL / VICON / SENSORMATIC / ELMO
Event Search, Time / Date Search,
Time line Search
VBS / VS 1.0 V (p-p) 75 Ω BNC x 4
VGA x1* 1
VBS 1.0 V (p-p) 75 Ω BNC x 1* 1
-8 dBs 27 kΩ unbalanced RCA x 4
-8 dBs 600 Ω unbalanced RCA x 1
Still image & Video data
ADSL, LAN / Dynamic IP supported
10BASE-T / 100BASE-TX
x 4
x 1 (0.5 A 12.5 V AC, 1 A 30 V DC)
[Values in parentheses are the relay ratings inside the DSR-2004.]
IR remote control can control up to 9 units
Input: 100 V to 240 V AC, 50/60 Hz Output: 12 V DC
25 W / 12 V
Temperature: 5°C to 40°C [41°F to 104°F], Humidity: 80% or less
350(W) x 65(H) x 260(D) mm [13.8 (W) x 2.6(H) x 10.2 (D) in]
3.2kg [112.9.oz] (with one HDD unit)
MODEL
Hard disk capacity
Picture resolution
Compression
Picture quality
Recording speed
Still image capture
Number of cameras
Menu language
Telemetry control protocol
Signal format
Video input
VGA output
Main monitor output
Audio input
Audio output
(USB 2.0 only)
Interface
LAN port
Sensor alarm input
Alarm output
Power source
Power consumption
Operating conditions
Dimensions
Weight
General
Search Mode
Video
Audio
Backup
Remote control
Electrical
Physical
NTSC
DSR-2004
350(13.8 )
65(2.6)
260(10.2)
[Unit: mm (inch)]
MPEG-4
The MPEG (Moving Picture Experts Group) 4
standard is designed to handle reproduction of
video with a wide dynamic range --- from video
streaming on a slow communication line to that
equivalent to HDTV quality. In MPEG-4, the
picture is broken down into objects, such as the
background, people, and buildings, and the
changes in respective objects are recorded. This is
similar to video recording in the M-JPEG format.
The subjects that can be treated as objects are
not limited to scenes and characters, but extend
to audio data such as speech and music.
Low Bit Rate but High Image Quality
MPEG-4 is capable of providing quality images at a
low bit-rate. It is possible to record for
considerably longer than systems using JPEG
compression.
Network
DSR-2004 offers network connectivity with LAN
and WAN. MPEG-4 is an international standard for
highly efficient digital encoding (compression) of
video and audio signals. This means it is also
highly efficient for transmission over a network.
Easy Backup (Only through USB 2.0)
Supports the use of USB 2.0 Flash Drives. This
makes it easy to backup still images in JPEG
format and video in AVI format.
Search Functions
Three search functions are available — ”Event
Search”, “Time / Date Search” and “Time line
Search” — find recordings instantly.
Other Features
•Full, QUAD and sequential display •LOG History
•Multi protocol RS-485 telemetry
720 x 480, 360 x 240 (pixels)
120IPS / 4ch (360 x 240/ch),
30 IPS / 4ch (720 x 480/ch)
NTSC standard (color) / EIA standard
(B/W) auto select, 525 lines, 120 IPS
720 x 480, 360 x 240
PAL
720 x 576, 360 x 288 (pixels)
720 x 576, 360 x 288
100IPS / 4ch (360 x 288/ch),
25 IPS / 4ch (720 x 576/ch)
PAL standard (Color) / CCIR standard
(B/W) auto select, 625 lines, 100 IPS
NETWORK
PC PC PC PC
Net
work
Control
signal
* 1 Either the video output or VGA output can be enabled at any one time.
