Instructions for the User
48
7. DESCRIPTION OF FRONT PANEL CONTROLS
All the control and monitoring devices are clearly in view on the front panel. The table below provides the
key to the symbols used.
OVEN THERMOSTAT FRONT LEFT-HAND COOKING ZONE
FUNCTION SELECTOR KNOB REAR LEFT-HAND COOKING ZONE
REAR RIGHT-HAND COOKING ZONE
FRONT RIGHT-HAND COOKING ZONE
Before using the oven, check that the display is showing the symbol (see point “11. ELECTRONIC
PROGRAMMER”).
HOB CONTROL KNOBS
Standard heating
The ring beside each knob identifies the corresponding cooking zone. To switch
it on, turn the knob to the required setting. Setting is on a gradual scale, so all
the intermediate positions between the numbers can be used.
To switch off the zone, return the knob to the setting
Dual heating
The ring beside each knob identifies the corresponding
cooking zone. To heat the inner cooking zone, turn the knob
to the required setting. To heat both cooking zones (inner
and outer) simultaneously, turn the knob to /
and then
release it. The knob will return to the maximum setting. To
regulate the heating level, turn the knob anti-clockwise to the
setting required. To return to heating of the inner cooking
zone, turn the knob to and then turn it to the required
setting. To switch off the zone, return the knob to
THERMOSTAT KNOB
The cooking temperature is selected by turning the knob clockwise to the
required setting, between 50° and 275°C.
The light comes on to indicate that the oven is heating up. This light goes out
when the set temperature is reached. Flashes at regular intervals to indicate
that the temperature inside the oven is being kept constantly at the set level.
