Spalding M5800041 User Manual
Page 11
11
01/06
ID# M5800041
Pole bracket will need to be lightly pressed into backboard ribbing. Be sure to press
completely into place. Attach rim to backboard and pole bracket (14) with nut (20),
reinforcement bracket (15), and carriage bolt (8) as shown. Tighten nut completely.
PRESS BRACKET
(14) INTO PLACE
HERE
XSHBM01.EPS
211208
SAWHORSE OR SUPPORT TABLE
8
15
14
6.
Carefully tip unit forward and slide backboard
assembly onto pole as shown.
12
13
20
