Functional Description and Specifications
Disconnect the plug from the power source before making any assembly,
adjustments or changing accessories. Such preventive safety measures
reduce the risk of starting the tool accidentally.
FIG. 1
LOWER GUARD
LOWER
GUARD LIFT
LEVER
BLADE WRENCH &
STORAGE AREA
AUXILIARY
HANDLE
BEVEL
ADJUSTMENT
WING NUT
CALIBRATED
BEVEL
QUADRANT
SAFETY SWITCH
UPPER
GUARD
Circular Saws
Model number 5580 5585
Maximum Capacities
Blade 7-1/4"
7-1/4"
Blade arbor hole Round Round
Depth of cut at 90° 2-7/16" 2-7/16"
Depth of cut at 45° 1-15/16" 1-15/16"
NOTE: For tool specifications refer to the
nameplate on your tool.
ADJUSTABLE
LINE GUIDE
FOOT
