SIM2 HTL40
RS-232C CONTROL SPECIFICATIONS
11
GAMMA
BE EF 03 19 00 13 25 02 27 08 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
(5)
MEMORY
BE EF 03 19 00 5E D5 02 27 09 00 00 01 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
(6)
(1) Returned value is indeterminate when the unit is in No Signal state.
Returned value may be different from the value displayed on the OSD, as in the latter, the values have
been normalized to the 0-100 range.
(2) Returned value is valid only when Video, S-Video, RGBS 15 kHz, YCrCb 15 kHz or YcrCb 32 kHz
signals are displayed. Returned value is indeterminate when other signals are displayed and when the
unit is in No Signal state.
(3) Returned value is valid only when Video (NTSC), S-Video (NTSC), RGBS 15 kHz, YCrCb 15 kHz
signals are displayed. Returned value is indeterminate when other signals are displayed and when the
unit is in No Signal state.
(4) Table below associates OSD labels with returned values:
Color Temperature
OSD Label Returned
value
High
00
Medium
01
Low
02
User
04
(5) Table below associates OSD labels with returned values:
Gamma
OSD Label Returned
value
Linear
00
Video
02
Graphics
03
Film
04
(6) Table below associates OSD labels with returned values:
Memory
OSD Label Returned
value
0 (Auto)
00
1 01
2 02
3
03
