Simplicity 14E - Manual (Page 5)

1
Table of Contents
ENGINE REFERENCE DATA
Safety Rules & Information
General ...................................................................2
Setting Up ...............................................................2
Operating Location..................................................3
Safe Wearing Apparel .............................................4
Operating Safety .....................................................4
Transporting and Storage .......................................5
Service and Maintenance .......................................5
Safety Decals ..........................................................6
Becoming Familiar With The Chipper/Shredder.......7
Assembling the Chipper Shredder ............................8
Controls & Operation ................................................11
Checks Before Starting .........................................11
Site Location .........................................................11
Engine Controls ....................................................12
Start-Up Procedure ...............................................12
Shut-Down Procedure...........................................12
Using Your Chipper/Shredder ..................................13
Description of General Functions..........................13
Proper Technique For Chipping ...........................14
Proper Technique for Shredding ...........................15
Waste Materials Guide..........................................17
Regular Maintenance ................................................18
Schedule ...............................................................18
Various Maintenance Procedures....................19-24
Storage .................................................................24
Repair .........................................................................25
Trouble Shooting...................................................25
Shredding Hammers .............................................26
Chipping Knives ....................................................28
Deflector................................................................31
Appendices
Specifications ........................................................31
Parts & Accessories ..............................................32
Technical Manuals ................................................32
For easy reference, please record the infor-
mation on the chart below.
The Equipment Reference Data can be found on the
identification tag located on the unit’s rear frame.
(Refer
to the Engine Owner’s Manual for location of engine
information serial number.)
WARNING
You must read, understand and comply with all safe-
ty and operating instructions in this manual before
attempting to set-up and operate your chipper/shred-
der.
Failure to comply with all safety and operating
instructions can result in loss of machine control,
serious personal injury to you and /or bystanders,
and risk of equipment and property damage. The tri-
angle in the text signifies important cautions or warn-
ings which must be followed.
WARNING
Engine exhaust from this product contains chemicals
known, in certain quantities, to cause cancer, birth
defects, or other reproductive harm.
Model Description/Number
M/N (Manufacturer’s Number)
EQUIPMENT REFERENCE DATA
S/N (Serial Number)
Dealer Name Date Purchased
Engine Make/Model Engine ID/Serial Number
