The amplifier shall be Atlas Sound CP700 Commercial Audio Amplifier.
The power amplifier shall have two channels. At 8 Ohms, 30Hz-
20kHz, it shall deliver 240 Watts per channel. At 4 Ohms, 1kHz, it shall
deliver 400 Watts per channel. At 2 Ohms, 1kHz, it shall deliver 550
Watts per channel. In bridge mono mode, with an 8 Ohm load, it shall
deliver 850 Watts. In bridge mono mode, with a 4 Ohm load, it shall
deliver 1100 Watts. The amplifier shall have internal circuits to protect
itself from output short circuits and thermal overload and will protect
attached loudspeakers from amplifier failure and DC voltages.

A variable speed fan shall provide heat sink cooling. Each channel to
have an input sensitivity of 1.25V, frequency response shall be 30Hz-
50kHz +0/-3dB direct mode and 30Hz-16kHz +0/-3dB in transformer
mode. Front panel indicators to include signal present, limiter, and
protection LEDs. Rear mounted stepped attenuators to provide
repeatability of gain settings. Input terminations shall be balanced
on barrier strip terminals or XLR female connectors. Loudspeaker
outputs shall be of the barrier strip type. A switch on the rear panel to
provide selection of Stereo, Parallel, and Bridge Modes of operation.
Dimensions shall be 5.19" X 18.9" X 16.85" and the amplifier shall
weigh 57 lbs.

ARCHITECT & ENGINEER SPECIFICATIONS

DIRECT POWER OUTPUTS

PROTECTION CIRCUITS

Max Average Power @ 35Hz-20kHz with 0.1% THD
(10-80k Filter)
8 Ohm, 30Hz-20KHz, 0.1% THD 240W x 2
8 Ohm, 1kHz, 0.1% THD 300W X 2
4 Ohm, 1kHz, 0.1% THD 400W X 2
2 Ohm, 1kHz, 0.1% THD 550W X 2

Bridged Mono 8 Ohm 850W
1kHz, 1% THD
Bridged Mono 4 Ohm 1100W
1kHz, 1% THD

Output Offset Voltage Protection
Heat Sink Overheat Protection
Transformer Overheat Protection
Load Shorting Protection
Soft Clip Limiters

TRANSFORMER OUTPUTS

CONTROLS

25V 280W X 2
70V 350W X 2
100V 350W X 2
140V Bridged 700W
200V Bridged 700W

Power Switch, Ch 1/Ch 2 gain (41 step)
Parallel/Stereo/Bridge Switch

FREQUENCY RESPONSE

COOLING

Direct Outputs (+0/-3dB) 30Hz-50kHz
Transformer Outputs (+0/-3dB) 30Hz-16kHz

Dual Speed Fan, Temperature Controlled

THD+N

INDICATORS

8 Ohm, 1kHz, 240W per channel <.05%

Power, Protect, Signal, Limit

SENSITIVITY

DIMENSIONS

Rated Ouput into 8 Ohms 1.25V

132mm X 480mm X 428mm (5.19" X 18.9" X 16.85")

VOLTAGE GAIN

NET WEIGHT

32dB

24.3kg (54 lbs)

INPUT IMPEDANCE

SHIPPING WEIGHT

Balanced/Unbalanced 20k/10k Ohm

26kg (57 lbs)

DAMPING FACTOR

8 Ohms Output, 10 Vrms >200dB

S/N RATIO

8 Ohms per Channel @ 240W 100dB

SPECIFICATIONS
