Setting up and connecting
SLB 450 A1
GB
IE
CY
Connecting the air hose
First connect the air hose ‹ 8 to the connection-support 2 of the pump .
With this, ensure that the plastic cam aligns exactly with the recess in the
connection-support
2 .
Then turn the hose connector of the air hose ‹ 8 to the left, in the direction of
the symbol , until the hose connector is clamped in the connecting support
2 of the pump .
2
8
Afterwards, insert the hose fi tting on the other side of the air hose ‹ 8 fi rmly
into the connection-support of the air-bubble mat 7 .
8
7
