10
ProSEAL ® 44 Pouch Board Laminator
MOUNTING USING A ProSEAL POUCH BOARD
Refer to the instruction sheet packed with each
box of ProSEAL Pouch Boards for specific
information on mounting/laminating with a
ProSEAL Board.
In addition, refer to the instruction sheet for
information on Compatible Media, Process
Conditions and technical information.
Carefully examine the board to determine
which edge is sealed. There is a 1/8" (3mm)
tape edge on the sealed end.
Starting at one of the corners, opposite the
sealed edge, gently lift and peel back the film.
Care should be taken not to break the sealed
hinge.
Center the image to be laminated on the board
and lay the film back over it.
Set the Control Knob to the correct setting that
matches the Pouch Board thickness.
Ensure that the unit is set to Hot Mode and that
the LED is not flashing
Slowly insert the Pouch Board into the inlet
opening. Ensure that the Pouch Board will
enter centered and straight. A gentle push
may be required to start the board into the
laminator.
Hold the edges of the Pouch Board until it is
engaged and the laminator begins pulling it
on its own.
The Pouch Board will feed through the
laminator and automatically exit at the rear of
the unit.
CAUTION! The board will be hot! Allow it
to lie flat while cooling.
If there is any dirt or adhesive on the surface
of the board, it can be removed by
dampening a lint free cloth with Isopropyl
Alcohol (IPA) and wiping the surface.
CAUTION! Always use care when using
Isopropyl Alcohol (IPA)! IPA is very
flammable.
The flash point of IPA is 11ºC (51.8ºF).
The self-ignition temperature is 400ºF
(752ºF).
