Functional Description and Specifications
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
! WARNING
Routers
CHIP DEFLECTOR
POP-UP
FINE ADJUSTMENT
KNOB
BASE CLAMP
LEVER
AIR VENTS
ON/OFF
TRIGGER
SWITCH
“LOCK ON”
BUTTON
BIT ROTATION ARROW
SUB-BASE
BASE
HANDLE
BASE
RELEASE
LEVER
DUST
PORT
SCALE
INDICATOR
DEPTH SCALE
VARIABLE
SPEED DIAL
(Model 1825 only)
FIG. 1
FIG. 2
