Specifications
Rev 1.0 Oct.09 11
Standards/Approvals
• Carrier specific approvals
• CE (Class A device per EN55022)
• RoHS
• FCC
• Industry Canada
• PTCRB
• This apparatus is suitable for use in Class I, Division 2,
Groups A, B, C, D or unclassified or non‐hazardous
locations.
Warning: Explosion Hazard - Substitution of any
components may impair suitability for Class I,
Division 2.
Host Interfaces
• Ethernet: 10BaseT RJ‐45
• USB Type B 5 Pin mini
• Antenna Connection:
· Cellular ‐ 50 Ohm SMA
· Receive Diversity ‐ 50 Ohm SMA
· I/O Ports: 2
Warning: The antenna should be installed no
closer than 20 cm from the human body. It is one of
the RSS-102 requirements for devices not requiring
SAR.
Dimensions
• 75mm x 27mm x 103mm
• 185 grams
Application Interfaces
• TCP/IP, UDP/IP, DHCP, HTTP, SNMP, SMTP, SMS, MSCI,
Modbus and more
LED Indicators
• Network
• Signal
• Activity
