Specifications – Speco Technologies 560 LINE COLOR BULLET CAMERA HT7715DNVW User Manual
Page 13

ITEM
HT7715DNV Series
Image Sensor
1/3” Sony Super-Had HQ-1 DSP CCD
Resolution
560 TV Line
Minimum illumination
0.03lux (IP Off) 0.00 LUX (IP on)
Lens Type
DC Auto Iris 4mm – 9mm (Varifocal)
CDS Sensor
Photoconductive Cells, Adjustable
Electronic Shutter
1/60 – 1/1000,000 seconds
Video Output
1.0vp-p into 75 ohms composite
TV System
NTSC
Scanning System
2 : 1 Interlace
Sync System
Line Locked / Adjustable V-Phase. Line Lock/Internal On-Off
S/N Ratio
More than 60db
IR Cut Filter
Mechanical – Auto Adjusts when required
Gamma Characteristic
0.45
Power Supply
24 Volts AC, 12 Volts DC – Dual Voltage
Power consumption
600mA
Operating Temperature
- 29℃ ~ +50℃ ( - 20℉ ~122℉)
Dimensions
2.4”W x 2.25”H x 7”L
Weight
1 lbs
Warranty
5Years
SPECIFICATIONS
13
