Speco Technologies VGA19LCD - Manual

17” or 19”
LCD Monitor
with VGA Input
Specifications
Display Resolution (Panel) 1280 x 1024 @ 75Hz 1280 x 1024 @ 75Hz
Active Area 337.920mm (H) x 270.336mm (V) 376.32mm (H) x 301.056mm (V)
Pixel Pitch 0.264mm 0.294mm
LCD Profile Ratio 5.4 5.4
Display Color 16.7 million colors 16.7 million colors
Brightness (Central) 300 cd/m 2 (typ.) 300 cd/m 2 (typ.)
Contrast Ratio 800:1 (typ.) 1000:1 (typ.)
Viewing Angle Left 80˚/Right 80˚/Up 80˚/Down 80˚ Left 85˚/Right 85˚/Up 85˚/Down 85˚
Response Time 5ms (typ.) 5ms (typ.)
Input Voltage 12V DC power supply included 12V DC power supply included
VGA Input 15pin D-SUB connector x 1 15pin D-SUB connector x 1
Audio Input 3.5mm stereo jack 3.5mm stereo jack
Speaker 1W + 1W 1W + 1W
Power Consumption 35 Watts 35 Watts
Operating Temperature 14ºF to 122ºF 14ºF to 122ºF
Storage Temperature -4ºF to 140ºF -4ºF to 140ºF
Dimensions 16.7” H x 16.4” W x 6.1” D 17.9” H x 17.8” W x 6.1” D
Weight 8.4 lbs. 10.1 lbs.
Note: These monitors do not have composite video connections.
Specifications subject to change
For more information contact us at:
Speco Technologies 200 New Highway, Amityville, NY 11701 Website: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
• VGA input works with most DVRs and computers
• Built-in internal amplifier and speakers
• 1280 x 1024 SVGA support for computer input
• Supports multiple language selections
• 2D comb filter and 2D de-interlace
• Desktop mount is removable to expose VESA 100 mounting holes
• Full OSD control of all monitor functions
VGA17LCD
17”
VGA19LCD
19”
Features:
12V DC Power Supply Power Cord User’s Manual Audio Cable VGA Cable
Included Accessories:
