Snapper 2700 PSI Pressure Washer
17
PARTS LIST — UNIT
Item Part #
Qty. Description
1
L190336GS
1
BASE
2
B2043GS
7
BOLT, Carriage
3
187978GS
1
KIT, Handle Hardware
4
C190293GS
1
HANDLE
5
CB1981GS
2
SUPPORT, Handle
6
99583GS
8
NUT, Hex Flange
7
B2150GS
1
HOOK, Square Neck Gun
8
B2516GS
3
CAP, Black Vinyl
9
CB1982GS
1
BUMPER
10
30809GS
6
GROMMET
11
187974AGS
1
DECAL, 5 QD Nozzles
12
190715GS
1
DECAL, Unit
13
190100GS
2
ASSY, Wheel
14
190146GS
2
PUSHNUT
15
48031GGS
1
CLAMP, Hose
16
A1040DGS
1
HOSE, Chemical Inject
17
A1041GS
1
FILTER, Chemical Hose
18
187625GS
1
HOSE
19
87815GS
1
GOGGLES, Safety
20
B1436BGS
1
GUN, with Molded Grip
21
23645GS
4
CAPSCREW, Socket Head
22
22237GS
4
WASHER, Lock
23
190666GS
1
MANUAL, Owners
24
B3858GS
1
ASSY, Wand Ext. with QD
25
MS6321
1
MANUAL, Engine
26
BB3061BGS
1
BOTTLE, Oil
28
190862GS
1
KIT, O-Ring Maintenance
29
188194GS
2
BLIND RIVET
31
191413GS
2
VIBE MOUNT, with Washer
33
B2126AGS
1
ASSY, PUMP (see pages 18-19)
34
21217GS
4
VIB MOUNT, Double Ended
35
67989GS
8
NUT, Flange
36
B4224GS
1
SCREEN, Gun Inlet
37
186839GS
1
INLET, Garden Hose
38
97837GS
1
O-RING, High Pressure Hose
39
95458GS
1
QUICK CONNECT
40
B1554GS
1
VALVE, Thermal Relief
41
186301GS
1
KIT, Nozzles QD
42
63281GS
1
KEY
43
187952GS
1
DECAL, Cool Down System
44
190277EGS
1
CARD, Owners Registration
45
190715GS
1
DECAL, PW, Snapper
46
11287628PGS 1
DIPSTICK, Pump
47
B2384GS
1
FILTER, Inlet
48
B4160GS
1
DECAL, Warning/Start
49
B3107GS
1
HOSE, Thermal Relief
50
48031BGS
2
CLAMP, Hose Band
900 NSP
1
ENGINE
