B U I LT- I N
I N S T A L L A T I O N S P E C I F I C A T I O N S
30"
(762)
84"
(2134)
36"
(914)
84"
(2134)
30"
(762)
84"
(2134)
36"
(914)
24"
(610)
84"
(2134)
83
3
/
4
"
(2127)
ROUGH OPENING
HEIGHT TO
FINISHED
FLOORING WITH
STANDARD
11" (279) GRILLE
83"
(2108)
MIN HEIGHT
REQUIRED TO
FINISHED
FLOORING
(LEVELERS IN)
75
1
/
2
"
(1918)
7"
(178)
6"
(152)
A
ROUGH OPENING WIDTH
24"
(610)
ROUGH
OPENING
DEPTH
E
3"
(76)
18"
(457)
W
LOCATE WATER SUPPLY
WITHIN SHADED AREA
LOCATE ELECTRICAL
WITHIN SHADED AREA
6"
(152)
SHUT-OFF
VALVE
FRONT VIEW
TOP VIEW
EXTEND
WATER LINE
APPROX 36" (914)
FROM BACK WALL
I N S T A L L A T I O N S P E C I F I C A T I O N S
Over-and-Under Models
Model 611
A)
Rough Opening Width
29
1
/
2
" (749)
B)
Min Door Clearance
30
1
/
8
" (765)
Model 611G
A)
Rough Opening Width
29
1
/
2
" (749)
B)
Min Door Clearance
30
1
/
8
" (765)
Model 650
A)
Rough Opening Width
35
1
/
2
" (902)
B)
Min Door Clearance
36
1
/
16
" (916)
Model 650G
A)
Rough Opening Width
35
1
/
2
" (902)
B)
Min Door Clearance
36
1
/
16
" (916)
Dimensions are for finished rough openings.
Door swing clearances are based on
stainless steel door and handle dimensions.
O V E R A L L D I M E N S I O N S
Over-and-Under Models
O V E R - A N D -
U N D E R
Model 611
Model 611G
with Glass Door
Model 650
Model 650G
with Glass Door
B
23
7
/
8
"
(606)
BEHIND
FRAME
3
/
8
"
(10)
FRAME
EXTENSION
90˚
3
Model 611
Width
30" (762)
Height
84" (2138)
Depth
24" (610)
Model 611G
with Glass Door
Width
30" (762)
Height
84" (2138)
Depth
24" (610)
Model 650
Width
36" (914)
Height
84" (2138)
Depth
24" (610)
Illustrations shown in stainless steel design.
Model 650G
with Glass Door
Width
36" (914)
Height
84" (2138)
Depth
24" (610)
